10″ PRO Sound PA Line Array Loudspeaker Audio System
- Frequency Response
- 80Hz~18kHz(±2dB)/70Hz~19kHz(-10dB)
- Adjusting Method
- by Software
- Sound Channel
- Combination
- Structure
- Bass Reflex Enclosure
- Function
- Conference Hall,Stadium,Multi-Functional Hall
- SNR
- Professional Speaker
Specifications
| Product name | 10″ PRO Sound PA Line Array Loudspeaker Audio System |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Model NO. | VK10 active system |
| Usage | Stage/DJ, Karaoke, Portable Player, Home Theater System, Auditorium,Stadium,Live Show |
| Adjusting Method | by Software |
| Sound Channel | Combination |
| Structure | Bass Reflex Enclosure |
| Function | Conference Hall,Stadium,Multi-Functional Hall |
| SNR | Professional Speaker |
| System | Single 10" Top+Active Single 18" Subwoofer |
| Frequency Response | 80Hz~18kHz(±2dB)/70Hz~19kHz(-10dB) |
| Power Rating(AES) | Hf:75W Lf:300W,Lf:900W |
| Nominal Impedance | 8Ω |
| Spl(Continuous/Peak) | Hf:128/134dB Lf:128/134dB |
| Speaker Unit | B&C |
| AMP Module | Powersoft AMP |
| DSP Module | Powersoft Module |
| Transport Package | Carton Box or Flight Case |
| Specification | 530*716*600mm |
| Origin | China |
| HS Code | 8518220000 |
| Production Capacity | 2000PCS/Month |
| Customization | Available |
| Amplification Type | Active |
| Speaker Material | Wood |
| Product name | 10" Top+18" Self-Powered Subwoofer With DSP |
| HF | 110dB LF:104dB |
| NEUTRIK NL4MP×2 HF | 2+2-,LF:1+1- |
| output power 4Ω | 2000W×4 |
| output power 8Ω | 1000W×4 |
| output power 16Ω | 600W×4 |
| Premium Components | B&C Speaker unit + |
| Our Advantages | 1) |
| Price | US$800.00-1,000.00 2 Pieces (MOQ) |
| Supplier | Guangzhou Ruifeng Intelligence Technology Co., Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Power Rating(AES) | |
|---|---|
| Speaker Material | Wood |
| Nominal Impedance | 8Ω |
| output power 4Ω | 2000W×4 |
| output power 8Ω | 1000W×4 |
| output power 16Ω | 600W×4 |
Additional data
| Frequency response | 80Hz~18kHz(±2dB)/70Hz~19kHz(-10dB) |
|---|---|
| Sensitivity( 1W/1m ) | HF:110dB LF:104dB |
| Nominal Impedance | HF:16Ω LF:16Ω |
| Power rating( AES ) | HF:75W LF:300W |
| LF Unit | 1×10"(Neodymium/65mm Voice Coil) |
| HF Unit | 1 ×3"(75mm voice coil ) |
| Dispersion(HxV) | 100°x10° |
| SPL(continue/peak) | HF:128/134dB LF:128/134dB |
| Connectors | NEUTRIK NL4MP×2 HF:2+2-,LF:1+1- |
| Dimension(H×W×D) | 308×593×435mm |
| Net Weight | 26( kg ) |
| System | 18"self-powered subwoofer with DSP | 4 channel D class | 2×Neutrik Powercon IN/OUT |
|---|---|---|---|
| Sensitivity(1W/1m) | 98dB | amplifier modular(with DSP) | output power 4Ω:2000W×4 output power 8Ω:1000W×4 output power 16Ω:600W×4 |
| Frequency response | 40Hz~200Hz(±2dB)/30Hz~300Hz(-10dB) | Gain | 32dB |
| Power rating(AES) | 900W | S/N | 115dB (A weight) |
| SPL(continuous/peak) | 127.5dB/132.5dB | RMON | with load impedance monitoring function |
| Nominal impedance | 8Ω | Operating voltage rang | AC90-264V, 50/60Hz |
| LF unit | 18"neodymium LF unit(100mm) | Dimension(H×W×D) | 581×593×660mm |
| Connectors | 1×Neutrik NL4 Speakon 4core plug(HI:2+2-,LF:1+1) | ||
| 1×Neutrik NL4 Speakon 4core plug(SUB:1+1-) | |||
| 2×Neutrik XLR IN/OUT | |||
| 1×Neutrik AES3 IN | |||
| 2×Ethernet port RJ45 IN/OUT | |||
| 2×Neutrik Powercon IN/OUT |
Product description
The supplier lists this product. Its stated application is Stage/DJ, Karaoke, Portable Player, Home Theater System, Auditorium,Stadium,Live Show. The listed model is VK10 active system. Supplier-stated function: Conference Hall,Stadium,Multi-Functional Hall. The specifications below reflect the information publicly displayed on the listing. Model NO.: VK10 active system. Frequency Response: 80Hz~18kHz(±2dB)/70Hz~19kHz(-10dB). Power Rating(AES): Hf:75W Lf:300W,Lf:900W. Nominal Impedance: 8Ω. Speaker Material: Wood. output power 4Ω: 2000W×4. output power 8Ω: 1000W×4. output power 16Ω: 600W×4.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 10″ PRO Sound PA Line Array Loudspeaker Audio System?
The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 10″ PRO Sound PA Line Array Loudspeaker Audio System cost?
The published price is US$800.00 – 1,000.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
VK10 active system · US$800.00 – 1,000.00 · MOQ 2 Pieces
