100W Program Power Loudspeaker, 1.75” Voice Coil, Ferrite Compression High Driver
- Impedance
- 8 Ohm
- Sensitivity
- 106dB
- Application
- Stage
- Activity
- Passive
- Operation Mode
- No
- Speaker Material
- Plastic
Specifications
| Product name | 100W Program Power Loudspeaker, 1.75” Voice Coil, Ferrite Compression High Driver |
|---|---|
| Category | Crossovers, Voice Coils, Cones & Repair Parts |
| Customization | Available |
| Activity | Passive |
| Model NO. | DE4437P |
| Operation Mode | No |
| Speaker Material | Plastic |
| Application | Stage |
| Certification | CE, RoHS, FCC |
| AES Power Rating | 50 W |
| Program Power | 100 W |
| Frequency Range | 1200-18000Hz |
| Sensitivity | 106dB |
| Voice Coil | 1.75''vc |
| Coil Material | Aluminum |
| Former | Kapton |
| Diaphragm Material | Polymer Materials |
| Impedance | 8 Ohm |
| Magnet | Ferrite |
| Transport Package | Carton |
| Specification | 322 x 244 x 148 mm |
| Origin | China |
| HS Code | 8518290000 |
| Production Capacity | 50000 |
| Price | US$5.00-17.00 12 Pieces(MOQ) |
| Supplier | GUANGDONG HIWELL AUDIO CO., LTD |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Plastic |
|---|---|
| AES Power Rating | 50 W |
| Program Power | 100 W |
| Coil Material | Aluminum |
| Diaphragm Material | Polymer Materials |
| Impedance | 8 Ohm |
Additional data
| Throat diameter | mm(in.) | 25.4(1) |
|---|---|---|
| Nominal impedance | Ω | 8 |
| DC resistance | Re Ω | 6 |
| Program power (1) | W | 100 |
| AES Power rating(2) | W | 50 |
| Sensitivity (3) | dB | 106 |
| Frequency range | Hz | 1200 ~ 18000 |
| Voice coil diameter | mm(in.) | 44(1.75) |
| Magnet material | Ferrite | |
| Magnet OD | mm | 100 |
| Coil material | ALR | |
| Former material | Kapton | |
| Diaphragm material | Polymer Materials | |
| Voice coil Inductance | mH | 0.08 |
| Flux density | T | 1.35 |
| Recommended crossover (4) | Hz | 1500 |
| Net weight | Kg | 1.4 |
|---|---|---|
| Multipack size(12) (WxDxH) | mm | 322 x 244 x 148 |
| Multipack weight | Kg | 17.8(12PCS) |
Product description
The supplier lists this product. Its stated application is Stage. The listed model is DE4437P. The specifications below reflect the information publicly displayed on the listing. Noise: 0. Model NO.: DE4437P. Speaker Material: Plastic. AES Power Rating: 50 W. Program Power: 100 W. Frequency Range: 1200-18000Hz. Sensitivity: 106dB. Coil Material: Aluminum. Diaphragm Material: Polymer Materials. Impedance: 8 Ohm.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 100W Program Power Loudspeaker, 1.75” Voice Coil, Ferrite Compression?
The listed minimum order quantity is 12 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 100W Program Power Loudspeaker, 1.75” Voice Coil, Ferrite Compression cost?
The published price is US$5.00 – 17.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
DE4437P · US$5.00 – 17.00 · MOQ 12 Pieces
