12inch Copper Line Array Neodymium MID Bass Audio Professional Speaker
Speaker Drivers, Woofers & Tweeters

12inch Copper Line Array Neodymium MID Bass Audio Professional Speaker

Model: 12WF8608N Customization available Speaker Parts & Accessories
US$20.00 – 80.00
MOQ 2 Pieces
Application
Commercial
Activity
Passive
Cone
Paper
Spider
USA Material
Voice Coil
3.5inch Copper in/Outside with Fiberglass Bobbin
Magnet
Neodymium
Send Inquiry Full specifications

Specifications

Product name12inch Copper Line Array Neodymium MID Bass Audio Professional Speaker
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
ActivityPassive
ApplicationCommercial
Model NO.12WF8608N
ConePaper
SpiderUSA Material
Voice Coil3.5inch Copper in/Outside with Fiberglass Bobbin
MagnetNeodymium
BasketAlu
Transport PackageStrong Carton
SpecificationNet Weight ( 1unit) 6.1 kg Shipping Weight
OriginGuangzhou, China
HS Code8518290000
Production Capacity3000/Month
https//ruizhengsound.en.made-in-china.com/product/GXcnBvRunZUS/China-15inch-86mm-Voice-Coil-Line-Array-Neodymium-MID-Bass-Speaker.html
PriceUS$20.00-80.00 2 Pieces(MOQ)
SupplierFoshan Ruizheng Audio Co.,Ltd
Data retrieved2026-10-23

Additional data

MODEL 12WF8608N
SpecificationsThiele Small Parameters
TYPEMid-bassFs59 Hz
Nominal Diameter300 mm/12 inRe5.3ohm
Rated impedance8 ohmQms7.6357
Nominal (AES)500 WQes0.2810
Continuous Program1000 WQts0.2700
Sensitivity(1w/1m)97.5 dBVas45.4.L
Frequency Range59Hz-3500HzSd0.055 m2
Voice Coil Diameter88 mm/3.5 inMms65.7 g
Voice Coil MaterialCopper out/inBL21.6 T.M
Mounting lnformationShipping lnformation
Overall Diameterφ317.5 mm/φ12.5inNet Weight ( 1unit)5.1 kg
Bolt Circle Diameterφ299 mm/φ11.8 inShipping Weight ( 1unit)6.3 kg
Mount Baffle Cut-outφ285mm/φ11.2 inPackage Size ( 1unit)34x34x18 cm
Depth142 mm/5.6 in
Bolt Hole Diameter8-7mm/8-0.28 in

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is 12WF8608N. The specifications below reflect the information publicly displayed on the listing. Model NO.: 12WF8608N.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 12inch Copper Line Array Neodymium MID Bass Audio Professional Speaker?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 12inch Copper Line Array Neodymium MID Bass Audio Professional Speaker cost?

The published price is US$20.00 – 80.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
