12inch Loudspeaker for MID bass with 190mm magnet,
- Style
- Circular
- Usage
- Expand Volume
- Cone
- Paper
- WORD nChannels
- 5.1Channel
- type 1
- Subwoofer
- type 2
- bluetooth speaker
Specifications
| Product name | 12inch Loudspeaker for MID bass with 190mm magnet, |
|---|---|
| Category | Other Speakers & Sound Systems |
| Cone | Paper |
| Usage | Expand Volume |
| WORD nChannels | 5.1Channel |
| Model NO. | 12AH975 |
| type 1 | Subwoofer |
| type 2 | bluetooth speaker |
| type 3 | powerful amplifier |
| type 4 | wireless speaker |
| type 5 | portable speaker |
| type 6 | PRO audio |
| type 7 | line array |
| magnet | ferrite |
| basket material | aluminum |
| cone material | fiber/pulp paper cone |
| application 1 | outdoor/indoor speaker |
| application 2 | stage/karaoke/DJ speaker |
| Category | Speaker |
| Transmission Mode | Air-conduction |
| Transducer Principle | Permanent Magnetic Speaker |
| Radiation Mode | Indirect Radiation Type |
| Style | Circular |
| Certification | SGS |
| Brand | DERWEL |
| Transport Package | Carton |
| Specification | 33*33*33 |
| Origin | Guangzhou |
| Production Capacity | 5000PCS/Month |
| Photos of the 12 inch MId bass loudspeaker | 12inch 190 magnet 75 voice Mid bass loudspeaker. |
| GENERAL SPECIFICATIONS | Nominal Diameter |
| PHYSICAL INFORMATION | Magnet |
| COMPANY INFORMATION | Guangzhou Shengguang Electronic Co. Ltd was established in |
| For sample | 10-15 days |
| For order | 30-45 days |
| Price | US$48.00 2 Pieces(MOQ) |
| Supplier | DERWEL AUDIO CO., LTD. |
| Data retrieved | 2026-10-23 |
Available options
| basket material | aluminum |
|---|---|
| cone material | fiber/pulp paper cone |
Additional data
| Nominal Diameter | 12 | Inch |
|---|---|---|
| Rated Impedance | 8 | Ω |
| Power Handling Capacity | 600 | Watts |
| Sensitivity 1W 1M | 96.7 | dB |
| Effective Piston Diameter | 260 | mm |
| Voice Coil Diameter | 75.5 mm | 3 Inch |
| Resonance Frequency | Fs | 57 | Hz |
|---|---|---|---|
| DC Resistance | Re | 5.8 | Ω |
| Mechanical Q Factor | Qms | 10.993 | |
| Electrical Q Factor | Qes | 0.326 | |
| Total Q Factor | Qts | 0.317 | |
| BL Factor | BL | 19.074 | TM |
| Effective Moving Mass | Mms | 57.483 | gr |
| Equivalent Cas Air Load | Vas | 54.939 | liters |
| Effective Piston Area | Sd | 0.053 | |
| Half-Space Efficiency | Eff | 2.962 | % |
| Top Palte Thickness | Hag | 8 | mm |
| Voice Coil Height | Hvc | 14 | mm |
| Voice Coil Over-Hung | Xmax | 8 | mm |
| Magnet | 190×90×20 Ferrite |
|---|---|
| Voice Coil Winding Material | Copper |
| Cone Material | Pulp Paper |
| Overall Diameter | 320mm |
| Mounting Holes | 8 holes ∅ 302mm |
| Total Depth | 135mm |
Product description
The supplier lists this product. Its stated application is Expand Volume. The listed model is 12AH975. The specifications below reflect the information publicly displayed on the listing. Model NO.: 12AH975. basket material: aluminum. cone material: fiber/pulp paper cone.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 12inch Loudspeaker for MID bass with 190mm magnet,?
The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 12inch Loudspeaker for MID bass with 190mm magnet, cost?
The published price is US$48.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Customization depends on the manufacturer and order quantity. Describe what you need and we will confirm the options.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
12AH975 · US$48.00 · MOQ 2 Pieces
