12inch PRO Sound Full Range Coaxial Speaker
Speaker Drivers, Woofers & Tweeters

12inch PRO Sound Full Range Coaxial Speaker

Customization available Speaker Parts & Accessories
Price on request
MOQ 2 Pieces
Sensitivity
97 dB / 108 dB
Application
Stage
Operation Mode
No
Speaker Material
Plastic
Certification
CE, RoHS, FCC
AES Power Rating
400 W / 110 W
Send Inquiry Full specifications

Specifications

Product name12inch PRO Sound Full Range Coaxial Speaker
CategorySpeaker Drivers, Woofers & Tweeters
Operation ModeNo
Speaker MaterialPlastic
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating400 W / 110 W
Program Power800 W / 220W
Voice Coil3''vc Ccaw in/out / 3''vc Aluminum
Frequency Range60-3000Hz / 500-18000 Hz
Sensitivity97 dB / 108 dB
Diaphragm MaterialTitanium
MagnetNeodymium
ChassisAluminum
Transport PackageCarton
Specification325 x 325 x 205 mm
OriginChina
HS Code8518290000
Production Capacity50000
CustomizationAvailable
ActivityPassive
PriceNegotiable 2 Pieces (MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

Speaker MaterialPlastic
AES Power Rating
400 W110 W
Program Power
800 W220W
Diaphragm MaterialTitanium

Additional data

Nominal diametermm(in.)311(12)
Nominal impedanceΩ8
Minimum impedanceΩ6.1
Program power (1)W800
AES Power rating(2)W400
Sensitivity (3)dB97
Frequency rangeHz60 ~ 3000
Voice coil diametermm(in.)75(3)
Chassis materialAluminum
Magnet materialNeodymium
Magnet dimensions (ODxIDxh)mm138 x 90 x 10
Coil materialCCAW
Former materialGlass Fiber
Xmax(4)mm7.5
Xmech(5)mm13
Gap heightmm8
Voice coil Wingding heightmm18
Diaphragm materialTitanium
Program power (1)W220
AES Power rating(2)W110
Sensitivity (3)dB108
Frequency rangeHz500 ~ 18000
Voice coil diametermm(in.)72(3)
Coil materialALR
DC resistanceReOhm5.3
Resonance frequencyFsHz60
Moving massMmsg50
ComplianceCmsmm/N0.14
Force factorBLN/A15.3
Mechanical Q-factorQms5.4
Electrical Q-factorQes0.45
Total Q-factorQts0.41
Equivalent air volumeVasI67
Voice coil InductanceLemH0.25
Diaphragm areaSdcm²581
Reference efficiencyEta 0%3.1
Net weightKg4.5
Multipack size (1) (W x D x H)mm325 x 325 x 205
Multipack weightKg5.1

Product description

The supplier lists this product. Its stated application is Stage. The specifications below reflect the information publicly displayed on the listing. Speaker Material: Plastic. AES Power Rating: 400 W / 110 W. Program Power: 800 W / 220W. Frequency Range: 60-3000Hz / 500-18000 Hz. Sensitivity: 97 dB / 108 dB. Diaphragm Material: Titanium. Noise: 0.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 12inch PRO Sound Full Range Coaxial Speaker?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 12inch PRO Sound Full Range Coaxial Speaker cost?

The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
