15W 8ohm Black HiFi Round Line Array Sound Bar Music Box Customize Speaker with Ce RoHS
- Material
- Metal
- Type
- Speaker
- Application
- Car Speaker etc
- Color
- Black
- Speaker Design
- Tweeter
- Shape
- Runway Shape
Specifications
| Product name | 15W 8ohm Black HiFi Round Line Array Sound Bar Music Box Customize Speaker with Ce RoHS |
|---|---|
| Category | Soundbars & Home Theater Systems |
| Customization | Available |
| Type | Speaker |
| Speaker Design | Tweeter |
| Model NO. | YD78-1N |
| Shape | Runway Shape |
| Material | Metal |
| Sound Frequency | High Pitch |
| Voltage | 1V |
| Energy Exchanging Mechanism | Electrical |
| Color | Black |
| Feature | Full Frequency |
| Function | Micro Speaker |
| Application | Car Speaker etc |
| Transport Package | 1000 Pieces Per Carton |
| Specification | metal |
| Origin | China |
| HS Code | 8518290000 |
| Production Capacity | 300000 Pieces Per Month |
| Price | US$1.99-7.99 2,000 Pieces(MOQ) |
| Supplier | Changzhou Wujin Yueda Electroacoustic Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Material | Metal |
|---|---|
| Voltage | 1V |
| Color | Black |
Additional data
| Sound pressure | 90±3(A)AT 1m/1w |
|---|---|
| VOICE COLL IMP | 8Ω |
| RESONANT FREQ | 180±20% HZ |
| Temperature | -25°C ~ 55°C |
| RATED POWER | 10W |
| MAX POWER | 15W |
| Weight | 257g |
| NO. | ITEM | SPECIFICATION | TESTING CONDITION |
|---|---|---|---|
| 1 | NOMINAL SIZE | 83X83 MM | |
| 2 | VOICE COLL IMP | 8Ω(DCR=6Ω±10%) | |
| 3 | RESONANT FREQ | F0=130±20% HZ | AT 2.8V |
| 4 | OUTPUT S.P.L | MEAN VALUE AT1.0,1.2,1.5,2.0 KHz 90±3dB | AT 1m /1w MEASUREMENT |
| 5 | FREQ RESPONSE | fo ~ 18 K Hz -10dB | -10dB |
| 6 | RATED POWER | 15 W | |
| 7 | MAX POWER | 30 W | |
| 8 | OPEARTION | MUST BE NORMAL | PROGRAM SOURCE 15 W |
| 9 | NOISE | MUST BE NORMAL | SINE WAVE 8.9 V |
| 10 | HEAT TEST | AFTER TEST MEET ITEM 8,9 | 55± 2ºC 16 HOURS |
| 11 | COLD TEST | AFTER TEST MEET ITEM 8,9 | -20± 3ºC 16 HOURS |
| 12 | HUMIDITY TEST | AFTER TEST MEET ITEM 8,9 | 40±2ºC 90~95%RH 48 HOURS |
| 13 | LOAD TEST | AFTER TEST MEET ITEM 8,9 | WHITE NOISE 15 W 100 HOURS |
| 14 | MAGNET | Ф50x23x4.5 NdFeB MATERIAL SIZE | |
| 15 | TOTAL FLUX | MAX WELL | |
| 16 | POLARIZATION | ||
| 17 | NET WEIGHT | 257g |
Product description
The supplier lists this product as Speaker. Its stated application is Car Speaker etc. The listed model is YD78-1N. Supplier-stated function: Micro Speaker. The specifications below reflect the information publicly displayed on the listing. Model NO.: YD78-1N. Material: Metal. Sound Frequency: High Pitch.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 15W 8ohm Black HiFi Round Line Array Sound Bar Music Box Customize?
The listed minimum order quantity is 2,000 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 15W 8ohm Black HiFi Round Line Array Sound Bar Music Box Customize cost?
The published price is US$1.99 – 7.99 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
YD78-1N · US$1.99 – 7.99 · MOQ 2,000 Pieces
