16 Ohm 150W Big Magnet Horn Speaker Driver
Speaker Drivers, Woofers & Tweeters

16 Ohm 150W Big Magnet Horn Speaker Driver

Model: P-1216HG Customization available Speaker Parts & Accessories
US$13.00200–499 Pieces
US$12.00500+ Pieces
MOQ 200 Pieces
Power
150W
Impedance
16 ohms
Sensitivity
116dB/W/M
Sound Pressure Level
116Db
Category
Drive unit
Connection Mode
Double Wire
Send Inquiry Full specifications

Specifications

Product name16 Ohm 150W Big Magnet Horn Speaker Driver
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
Impedance16 ohms
Power150W
Model NO.P-1216HG
Sound Pressure Level116Db
UsageAlarms, Automotive Industry, Electronic Device, Industrial Equipment, Medical Device, Security System, Accept, Expand Volume, Monitor, High Fidelity
CategoryDrive unit
Connection ModeDouble Wire
Contact Pointwith Contact Point
Energy Exchanging MechanismElectrical
ShapeRound
Housing MaterialAL
FunctionPublic Address
Usefor Loudspeaker
Transport PackageCarton Box
OriginChina
HS Code8518290000
Package Size32.00cm * 32.00cm * 27.00cm
Package Gross Weight28.600kg
Power InputRMS 150 Wattes
Ferrite magnet1*D140mm*D75mm*20mm Y30
Rated impedance16 ohms
Sensitivity116dB/W/M
Freq Resp150 Hz to 6500 Hz
Horn coupling1-3/8 18 TPI
Packing1PC/box or according to the clients' requirement
BrandOEM/ODM acceptable
PriceUS$13.00 200-499 Pieces US$12.00 500+ Pieces
SupplierAntel Electronics (Shanghai) Co., Ltd.
Data retrieved2026-10-23

Available options

Power150W
Housing MaterialAL
Impedance16 ohms
Power InputRMS 150 Wattes
Rated impedance16 ohms

Additional data

P-1216HG Drive Unit
Power Input: RMS 150 Wattes
Ferrite magnet: 1*D140mm*D75mm*20mm Y30
Rated impedance: 16 ohms
Sensitivity: 116dB/W/M
Freq Resp:150 Hz to 6500 Hz
Horn coupling:1-3/8 18 TPI

Product description

The supplier lists this product. Its stated application is Alarms, Automotive Industry, Electronic Device, Industrial Equipment, Medical Device, Security System, Accept, Expand Volume, Monitor, High Fidelity. The listed model is P-1216HG. Supplier-stated function: Public Address. The specifications below reflect the information publicly displayed on the listing. Impedance: 16 ohms. Power: 150W. Model NO.: P-1216HG. Housing Material: AL. Power Input: RMS 150 Wattes. Rated impedance: 16 ohms. Sensitivity: 116dB/W/M.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 16 Ohm 150W Big Magnet Horn Speaker Driver?

The listed minimum order quantity is 200 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 16 Ohm 150W Big Magnet Horn Speaker Driver cost?

The published price is US$12.00 – 13.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
