18inch Loose Woofer Audio Professional Speaker Element High Spl Loudspeaker
Speaker Drivers, Woofers & Tweeters

18inch Loose Woofer Audio Professional Speaker Element High Spl Loudspeaker

Model: S18WF10015 Customization available Speaker Parts & Accessories
US$40.00 – 150.00
MOQ 2 Pieces
Type
Subwoofer
Application
Commercial
Voice Coil
100mm Copper Voice Coil in/out
Magnet
Y30A Ceramic
Cone
Tai Wan Cone with UK Coating
Spider
2 Spiders with Silicone USA Material
Send Inquiry Full specifications

Specifications

Product name18inch Loose Woofer Audio Professional Speaker Element High Spl Loudspeaker
CategorySpeaker Drivers, Woofers & Tweeters
Model NO.S18WF10015
Voice Coil100mm Copper Voice Coil in/out
MagnetY30A Ceramic
ConeTai Wan Cone with UK Coating
Spider2 Spiders with Silicone USA Material
TypeSubwoofer
BasketAlu
Transport PackageDouble Strong Carton
SpecificationNet Weight ( 1 unit) 14 kg
OriginGuangzhou, China
HS Code8518290000
Production Capacity3000/Month
CustomizationAvailable
ActivityPassive
ApplicationCommercial
https//ruizhengsound.en.made-in-china.com/product/fdpacBVvhrkT/China-Professional-Audio-12inch-Neodymium-12wf10008n-600W-Loud-Sound-Professional-Party-Speaker.html
PriceUS$40.00-150.00 2 Pieces (MOQ)
SupplierFoshan Ruizheng Audio Co.,Ltd
Data retrieved2026-10-23

Additional data

MODEL S18WF10015
SpecificationsThiele Small Parameters
TYPESubwooferFs37 Hz
Nominal Diameter460 mm/18 inRe5.1 ohm
Rated impedance8 ohmQms6.76
Nominal (AES)1000 WQes0.39
Continuous Program2000 WQts0.37
Sensitivity(1w/1m)97dBVas203 L
Frequency Range34Hz-1500HzSd0.1295 m2
Voice Coil Diameter100 mm/4 inMms202 g
Voice Coil MaterialCopper out/inBL25 T.M
Mounting lnformationShipping lnformation
Overall Diameterφ460 mm/φ18 inNet Weight ( 1 unit)12.2kg
Bolt Circle Diameterφ440 mm/φ17.3 inShipping Weight ( 1 unit)14 kg
Mount Baffle Cut-outφ422 mm/φ16.6 inPackage Size ( 1 unit)50x50x24 cm
Depth200 mm/7.9 in
Bolt Hole Diameter8-φ78/φ0.28 in

Product description

The supplier lists this product as Subwoofer. Its stated application is Commercial. The listed model is S18WF10015. The specifications below reflect the information publicly displayed on the listing. Model NO.: S18WF10015.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
