18sw115-8nw Neo Subwoofer with 1700W
Subwoofers

18sw115-8nw Neo Subwoofer with 1700W

Model: 18SW115-8NW Customization available Speakers & Audio Systems
US$243.0030–99 Pieces
US$232.00100–199 Pieces
US$221.00200+ Pieces
MOQ 30 Pieces
Application
Professional Audio
Noise
<102dB
Hi-Fi
PA
Activity
Compatible
Operation Mode
Compatible
Speaker System
Compatible
Send Inquiry Full specifications

Specifications

Product name18sw115-8nw Neo Subwoofer with 1700W
CategorySubwoofers
CustomizationAvailable
Noise<102dB
Hi-FiPA
Model NO.18SW115-8NW
ActivityCompatible
Operation ModeCompatible
Speaker SystemCompatible
Speaker MaterialCompatible
ApplicationProfessional Audio
CertificationCE, RoHS
MonitorCompatible
THD<0.005%
AES Power Handling1700W
Voice Coil Diameter116mm
F032Hz
Xmax17.5mm
Transport PackageCarton
SpecificationNeodymium, NW 11.9kg
OriginChina
HS Code85182900
Production Capacity36000pieces/Year
Package Size49.50cm * 49.50cm * 28.50cm
Package Gross Weight14.000kg
Lead Time7 days (1 - 30 Pieces) To be negotiated ( > 30 Pieces)
KEY FEATURES97dB 1W/1m sensitivity
GENERAL SPECIFICATIONSPart Number
NOTES1
Our quality management system is certified under ISO 90012015, and we hold multiple invention patents.
PriceUS$243.00 30-99 Pieces US$232.00 100-199 Pieces US$221.00 200+ Pieces
SupplierDongguan Weijiasheng Technology Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialCompatible
AES Power Handling1700W
Voice Coil Diameter116mm

Additional data

Part Number18SW115-8NW
Nominal Diameter460mm (18in)
Nominal Impedance8Ω
Minimum Impedance6.0Ω
AES Power Handling11700W
Maximum Power Handling23400W
(1W/1m) Sensitivity (1W/1m)397dB
Resonance Frequency32Hz
Frequency Range32Hz-1kHz
Voice Coil Diameter116mm
Winding MaterialCopper
Former MaterialGlass Fiber
Winding Depth35mm
Magnetic Gap Depth14mm
Xmax417.5mm
Flux Density1.15T
Basket MaterialCast Aluminum
Magnet MaterialNeodymium Inside Slug
Suspension MaterialDouble Fabric
Surround MaterialW-Roll Cloth-sealed
Cone MaterialCurvilinear Paper
Net Weight11.9kg
Model Number18SW115-8NW
Fs32Hz
Re5.6Ω
Le0.81mH
Mms327g
Mmd303g
Cms0.08mm/N
BL27.8Tm
Qms7.4
Qes0.47
Qts0.44
Vas160L
Ref. Efficiency1.1%
Sd1225cm2
EBP68Hz

Product description

The supplier lists this product. Its stated application is Professional Audio. The listed model is 18SW115-8NW. The specifications below reflect the information publicly displayed on the listing. Noise: <102dB. Model NO.: 18SW115-8NW. Speaker Material: Compatible. AES Power Handling: 1700W.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 18sw115-8nw Neo Subwoofer with 1700W?

The listed minimum order quantity is 30 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 18sw115-8nw Neo Subwoofer with 1700W cost?

The published price is US$221.00 – 243.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
