1u Digital Amplifier Professional Stage Audio Power Amplifier
Speaker Amplifiers & Audio Processors

1u Digital Amplifier Professional Stage Audio Power Amplifier

Model: D series Customization available Cables, Adapters & Audio Electronics
US$100.00 – 1,500.00
MOQ 2 Pieces
Type
Power Amplifier
Application
Commercial
Noise
<102dB
Activity
Active
Speaker Material
Metal
Certification
CE, RoHS, CCC, FCC, ETL, MET
Send Inquiry Full specifications

Specifications

Product name1u Digital Amplifier Professional Stage Audio Power Amplifier
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
Noise<102dB
ActivityActive
Model NO.D series
Speaker MaterialMetal
ApplicationCommercial
CertificationCE, RoHS, CCC, FCC, ETL, MET
TypePower Amplifier
8ohm4X2000W
4ohm4X3400W
2ohm4X4760W
Net Weight12kg
Dimension483X370X44mm(Wxhxd)
WarrantyTwo Years Free Warranty
Voltage90-260V
Size1u
Transport PackageQuality Carton Box or AMP Rack
SpecificationCE, RoHS
OriginChina
HS Code851850
Production Capacity10000 PCS/Month
PriceUS$100.00-1,500.00 2 Pieces(MOQ)
SupplierCVR PRO AUDIO CO.,LTD
Data retrieved2026-10-23

Available options

Speaker MaterialMetal
Voltage90-260V
Size1u

Additional data

ModelD-3002D-2004D-1504D-2002D-1502D-1004D-1002D-802
8Ω/Stereo2×3000W4×2000W4×1500W2×2000W2×1500W4×1000W2×1000W2×800W
4Ω/Stereo2×5100W4×3400W4×2550W2×3400W2×2550W4×1700W2×1700W2×1360W
2Ω/Stereo2×7140W4×4760W4×3570W2×4760W2×3570W4×2890W2×2890W2×2310W
16Ω/Bridge6000W2×4000W2×3000W4000W3000W2×2000W2000W2×1600W
8Ω/Bridge10200W2×6800W2×5100W6800W5100W2×3400W3400W2720W
4Ω/Bridge14280W2×9520W2×7140W9520W7140W2×5780W5780W4620W
Output RMS voltage RMS154.9V126.5V109.5V126.5V109.5V89.4V89.4V80.0V
Slew rate50V/us50V/us50V/us50V/us50V/us50V/us50V/us50V/us
SensitivitySelectableSelectable
41dB38dB
38dB35dB
35dB32dB
32dB29dB
THD+N0.01%0.01%0.01%0.01%0.01%0.01%0.01%0.01%
IMD-SMPTE0.01%0.01%0.01%0.01%0.01%0.01%0.01%0.01%
DIME300.01%0.01%0.01%0.01%0.01%0.01%0.01%0.01%
Cross-talk≥90dB≥90dB≥90dB≥90dB≥90dB≥90dB≥90dB≥90dB
Frequency response±0.2dB±0.2dB±0.2dB±0.2dB±0.2dB±0.2dB±0.2dB±0.2dB
Input impedance0kΩ(Balance), 10kΩ(Unblance)
Damp factor≥5000
SNR≥115dB≥112dB≥110dB≥110dB≥110dB≥110dB≥110dB≥110dB
Main power90~260VAC, 50~60Hz
ProtectionUnder voltage, DC, temperature, over load limiter, Short protection
Size (W×H×D)483×44×465mm483×44×370mm
Net weight12kg12kg12kg9kg9kg9kg9kg9kg

Product description

The supplier lists this product as Power Amplifier. Its stated application is Commercial. The listed model is D series. The specifications below reflect the information publicly displayed on the listing. Noise: <102dB. Model NO.: D series. Speaker Material: Metal.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 1u Digital Amplifier Professional Stage Audio Power Amplifier?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 1u Digital Amplifier Professional Stage Audio Power Amplifier cost?

The published price is US$100.00 – 1,500.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
