2 X 1.5mm2 Shielded Silicone LSZH Sound Audio Control Cable
US$3.99
MOQ 1,000 Meters
- Type
- Insulated
- Application
- Overhead, Heating, Underground
- Conductor Type
- Stranded
- Conductor Material
- Copper
- Sheath Material
- PVC
- Insulation Material
- PVC
Specifications
| Product name | 2 X 1.5mm2 Shielded Silicone LSZH Sound Audio Control Cable |
|---|---|
| Category | AUX, Analog & Interconnect Cables |
| Customization | Available |
| Type | Insulated |
| Conductor Type | Stranded |
| Model NO. | KVVP |
| Application | Overhead, Heating, Underground |
| Conductor Material | Copper |
| Sheath Material | PVC |
| Insulation Material | PVC |
| Material Shape | Round Wire |
| Range of Application | Control Cable |
| Certification | ISO9001, CE, CCC, RoHS, VDE, IEC |
| Brand | Chanelectric |
| Cable Color | Black Red as Required |
| Cable Length | to Be Cut in Length |
| Cable Quality | 36 Months After Shipping |
| Cable Cores | 1 Core, 2 Cores, 3 Cores, 4 Cores, 3+1 Cores |
| Cable Service | to Be Cut, to Be Assembiled |
| Cable OEM | Available |
| Cable Special | Available, Can Be Designed |
| Cable Test | Doing Against Each Orders |
| Cable Temperature | 70 Centi Degree |
| Cable Stock | in Stock |
| Cable Delivery | 10 Days |
| Cable Certificate | UL CCC VDE CE Test Report |
| Cable Shield | Braid, Screen, Al-Foil Tape |
| Cable Size | 0.1mm2-630mm2 |
| Cable Standard | IEC ASTM Icea UL BS |
| Transport Package | 500 Meters a Reel |
| Specification | 2.0 mm control cable |
| Origin | China |
| HS Code | 8544492100 |
| Production Capacity | 1000K a Day |
| Package Size | 220.00cm * 1000.00cm * 220.00cm |
| Package Gross Weight | 1800.000kg |
| Lead Time | 5 days (1 - 1000 Meters) To be negotiated ( > 1000 Meters) |
| control cable voltage | 450/750v |
| cores | multi-conductor, 2 cores control cable, 3 cores control cable, 4 cores control cable, etc |
| YY control cable | PVC insulation PVC sheath control cable,Unscreened or unshield felxible KVV KVVR |
| Application of control cable | electric signal control, electrical panels |
| standard | IEC 60502 |
| conductor | copper -solid, stranded, flexible annealed copper wires |
| insulation | PVC |
| filler | non-hyfroscopic material |
| shield | copper wire braid, copper tape shield, my-lar tape |
| outer jacket | PVC |
| its delivery | 10 days with customer deposit received |
| Color coding | 1 conductor cable -blue or yellow-green; 2 conductors cable - blue,brown; - yellow-green,black for sect > 10 mm²; |
| More than 5 conductors | - numbered black conductors; - yellow-green and numbered conductors. |
| Our factory mainly produces & sells | high temperature resistant wire & cable, silicone wire & cable, TPE wire & cable, PVC wire & cable, silicone braided wire, double insulated wire,electric control cable, instrument cable, underground cable, overhead cable, cable harness and cable assembly work |
| Price | US$3.99 1,000 Meters(MOQ) |
| Supplier | Chang'an International Trade (Henan) Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Conductor Material | Copper |
|---|---|
| Sheath Material | PVC |
| Insulation Material | PVC |
| Material Shape | Round Wire |
| Cable Color | Black Red as Required |
| Cable Length | to Be Cut in Length |
Additional data
| China market control cable Type | control cable type description | Application chanelectric control cable |
|---|---|---|
| KVV | Control cable with Cu core,PVC insulation and sheath | Lay in a fixed place,such as indoors,cable trench and conduit |
| KVVP | Control cable with Cu core,PVC insulation and sheath, braided shielding | For laying indoors,in cable trench and conduit,the cable should be shielded and for fixed installation. |
| KVVP2 | Control cable with Cu core,PVC insulation and sheath,copper tape shielding | For laying indoors,in cable trench and conduit,the cable should be shielded and for fixed installation. |
| KVVP3 | Control cable with Cu conductor,PVC insulation,PVC sheath and Aluminum polyester tape | For laying indoors,in cable trench and conduit,the cable should be shielded and for fixed installation. |
| KVV22 | Control cable with Cu core,PVC insulation and sheath,steel tape armoring | For laying indoors,in cable trench,and conduit and underground,able to bear heavier pulling force,and for fixed installation. |
| KVVP2-22 | Control cable with Cu conductor,PVC insulation,PVC sheath and steel tape armred | For laying indoors,in cable trench,and conduit and underground,able to bear heavier pulling force,the cable should be shielded and for fixed installation. |
| KVV32 | Control cable with Cu core,PVC insulation and sheath,steel wire armoring | For laying indoors,in trenches,and ducts and down well,able to bear heavier pulling force,and for fixed installation. |
| KVVR | Control cable with Cu core,PVC insulation and sheath | To be laid indoor with demand on mobility and softness |
| KVVRP | Control cable with Cu core,PVC insulation and sheath,braiding shielding | To be laid indoor with demand on shielding and softness |
| control cable material can be changed as customer design, so any inquiry about control cable, welcome to contact chanelectric in direct, very good price you will have from chanelectric team. |
| Control cable size | cores numer | conductor | OD. | apprx. weight | conductor resistance |
|---|---|---|---|---|---|
| # | mm2 | mm | kg/km | ohm/km | |
| 2C X 0.75 MM2 | 2 | 0.75 | 5.9 | 50 | 26 |
| 2CX 1.0 MM2 | 2 | 1 | 6.2 | 55 | 19.5 |
| 2C X1.5MM2 | 2 | 1.5 | 6.8 | 80 | 13.3 |
| 2CX2.5 MM2 | 2 | 2.5 | 8.4 | 135 | 7.98 |
| 2C X4.0 MM2 | 2 | 4 | 10.4 | 197 | 4.95 |
| 2CX6.0 MM2 | 2 | 6 | 12 | 225 | 3.3 |
| 2CX10 MM2 | 2 | 10 | 14.8 | 460 | 1.91 |
| JP standard name of control cable description | ||||
|---|---|---|---|---|
| Symbol | MAX. Operating Temperature of conductor | Insulation Materials | Sheath Materials | Application |
| CVV | 60 | PVC | PVC | General use |
| CEV | 75 | Polyethylene | PVC | |
| CCV | 90 | Crosslinked Polyethylene | PVC | |
| CEE | 75 | Polyethylene | Polyethylene (Black) | Chemical resistance |
| CCE | 90 | Crosslinked Polyethylene | Polyethylene (Black) |
| control cable conductor can be rigid copper wire, stranded copper wire, multi strands flexible copper wire | |||||
|---|---|---|---|---|---|
| Nominal | Conductor Structure | Insulation Thickness | Sheath Thickness | Approx. | Approx. Weight |
| Size | Overall Dia. | ||||
| mm2 | No./mm | mm | mm | mm | kg/km |
| 2×0.75 | 7/0.37 | 0.6 | 1.2 | 7.1 | 62 |
| 3×0.75 | 7/0.37 | 0.6 | 1.2 | 7.4 | 71 |
| 4×0.75 | 7/0.37 | 0.6 | 1.2 | 8.1 | 87 |
| 5×0.75 | 7/0.37 | 0.6 | 1.2 | 8.8 | 106 |
| 6×0.75 | 7/0.37 | 0.6 | 1.2 | 9.4 | 123 |
| 7×0.75 | 7/0.37 | 0.6 | 1.2 | 9.4 | 129 |
| 8x0.75 | 7/0.37 | 0.6 | 1.2 | 10.1 | 144 |
| 10x0.75 | 7/0.37 | 0.6 | 1.2 | 11.7 | 182 |
| 12x0.75 | 7/0.37 | 0.6 | 1.5 | 12.7 | 219 |
| 14x0.75 | 7/0.37 | 0.6 | 1.5 | 13.3 | 247 |
| 16x0.75 | 7/0.37 | 0.6 | 1.5 | 13.9 | 277 |
| 19x0.75 | 7/0.37 | 0.6 | 1.5 | 14.6 | 314 |
| 24x0.75 | 7/0.37 | 0.6 | 1.5 | 16.9 | 393 |
| 27x0.75 | 7/0.37 | 0.6 | 1.5 | 17.3 | 426 |
| 30x0.75 | 7/0.37 | 0.6 | 1.5 | 17.9 | 466 |
| 37x0.75 | 7/0.37 | 0.6 | 1.7 | 19.6 | 574 |
| 44x0.75 | 7/0.37 | 0.6 | 1.7 | 21.9 | 679 |
| 48x0.75 | 7/0.37 | 0.6 | 1.7 | 22.3 | 722 |
| 52x0.75 | 7/0.37 | 0.6 | 1.7 | 22.8 | 770 |
| 61x0.75 | 7/0.37 | 0.6 | 1.7 | 24.3 | 889 |
| control cable cores color |
|---|
| Color coding : 1 conductor cable -blue or yellow-green; 2 conductors cable - blue,brown; - yellow-green,black for sect > 10 mm²;3 conductors - brown,black,gray; - yellow-green, blue,brown;4 conductors - blue, brown, black,gray; - yellow-green, brown,black,gray;5 conductors - blue, brown, black, gray, black; - yellow-green, blue, brown, black,gray;More than 5 conductors: - numbered black conductors; - yellow-green and numbered conductors. |
Product description
The supplier lists this product as Insulated. Its stated application is Overhead, Heating, Underground. The listed model is KVVP. The specifications below reflect the information publicly displayed on the listing. Model NO.: KVVP. Conductor Material: Copper. Sheath Material: PVC. Insulation Material: PVC. Material Shape: Round Wire.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 2 X 1.5mm2 Shielded Silicone LSZH Sound Audio Control Cable?
The listed minimum order quantity is 1,000 meters. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 2 X 1.5mm2 Shielded Silicone LSZH Sound Audio Control Cable cost?
The published price is US$3.99 per meter. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
2 X 1.5mm2 Shielded Silicone LSZH Sound Audio Control Cable
KVVP · US$3.99 · MOQ 1,000 Meters
KVVP · US$3.99 · MOQ 1,000 Meters
Inquiry sent
Related products
All AUX, Analog & Interconnect Cables →
Low Voltage Data Signal Audio Control Cable for Security Alarm System Analog Audio and Control
US$0.05
MOQ 10,000 Meters
Manufacturer Supplier Hot Selling, Racing Earphone 7.1 to 3.5mm Audio Cable
