2000W 110V DSP6kq DSP Professional Audio 220V Power Amplifier with Ethernet
Speaker Amplifiers & Audio Processors

2000W 110V DSP6kq DSP Professional Audio 220V Power Amplifier with Ethernet

Model: DSP6KQ Customization available Cables, Adapters & Audio Electronics
US$700.00 – 750.00
MOQ 1 Piece
Frequency Response
±0.25dB,20Hz --- 20KHz
Type
Professional Amplifier
Usage
KTV, Bar, Disco
Used For
Professional
Tube Type
Transistor Amplifier
Function
Amplifier Combined
Send Inquiry Full specifications

Specifications

Product name2000W 110V DSP6kq DSP Professional Audio 220V Power Amplifier with Ethernet
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
TypeProfessional Amplifier
UsageKTV, Bar, Disco
Model NO.DSP6KQ
Used ForProfessional
Tube TypeTransistor Amplifier
FunctionAmplifier Combined
Sound Channel4
Output Number4
Voltage110V/220V/90V-240V
Element NumberPush-Pull Amplifier
Conductive ModeD
8ω Stereo Power(RMS)4X900W
4ω Stereo Power(RMS)4X1600W
2ω Stereo Power(RMS)4X2000W
InputsNeutrik XLR
OutputsNeutrik
Control InterfacesEthernet (Rj-45), RS485, USB Front & Rear)
Presets/Storage20 Factory Presets, User-Editable Memory
Net Weight13kg
Gross Weight18kg
Warranty2 Years
Transport PackageExport Standard Durable Carton Box
Specification483×377×88mm
OriginChina
HS Code8518400000
Production Capacity2000 Pieces/Month
Package Size18.00cm * 58.00cm * 60.00cm
Package Gross Weight18.000kg
Lead Time5 days (1 - 10 Pieces) 15 days (11 - 50 Pieces) To be negotiated ( > 50 Pieces)
MODELDSP6KQ
Input4CH
Output4CH
PC Com Port1 USB Com Port on front panel, 1 USB Com Port,2 RS485 Com Port on back panel (RJ-45)
Processor48KHz Sampling frequency, 48-bit Fixed-Point DSP, 24-bit A/D and D/A converter
Dynamic range>110dB
Frequency Response±0.25dB,20Hz --- 20KHz
Distortion<
Signal to noise ratio>110dB
crossover filterEach
adjusted,Filter typeButterworth,
Frequency20Hz---20KHz,Slope:12,18,24 or 48 dB/octave
Bandwidth0.2
to 36 oct,Frequency20Hz to 20KHz,
Gain-24dB to +12dB, step:0.2 dB
Delay0ms to 115ms
Display2 x
Store Settings20
THD+N1KHz
High-current output2*1500W @ 2 ohms; 2*1250W @ 4 ohms
Ultra-lightweight densityWeighs just 13kg
Application ScenariosLive Sound Reinforcement----Ideal for portable PA systems requiring high power density in a lightweight rack.
The delivery timeit is 8-10 days if by air; it is 45-60 days if by sea.
PriceUS$700.00-750.00 1 Piece(MOQ)
SupplierAscsonic Audio Technology Co., Ltd
Data retrieved2026-10-23

Available options

Voltage110V/220V/90V-240V
8ω Stereo Power(RMS)4X900W
4ω Stereo Power(RMS)4X1600W
2ω Stereo Power(RMS)4X2000W

Additional data

Ascsonic Professional 4 Channels 2U Line Array Digital DSP Audio Power Amplifier
MODEL:DSP6KQDSP10KQ
DSP SPECIFICATION
Input:4CH4CH
Output:4CH4CH
PC Com Port:1 USB Com Port on front panel, 1 USB Com Port,2 RS485 Com Port on back panel (RJ-45)
Processor:48KHz Sampling frequency, 48-bit Fixed-Point DSP, 24-bit A/D and D/A converter
Dynamic range:>110dB
Frequency Response:±0.25dB,20Hz --- 20KHz
Distortion:< 0.01%, 20Hz - 20KHz @ +10dBu balanced input
Signal to noise ratio:>110dB
crossover filter:Each output channel can be independently set as LPF and HPF, The parameters can be adjusted,Filter type:Butterworth, Bessel, Linkwitz-Riley;The Crossover Frequency:20Hz---20KHz,Slope:12,18,24 or 48 dB/octave
EQ:Bandwidth:0.2 to 36 oct,Frequency:20Hz to 20KHz, Gain: -24dB to +12dB, step:0.2 dB
Delay:0ms to 115ms
Display:2 x 20 LCD
Store Settings:20 user program dynamic storage
Eternet functionYes
AMPLIFICATION SPECIFICATION
ModelDSP 6KQDSP 10KQ
8Ω Stereo Power4x900W4x1350W
4Ω Stereo Power4x1600W4x2200W
2Ω Stereo Power4x2000W4x2500W
8Ω Bridged Monon Power2x3500W2x4400W
4Ω Bridged Monon Power2x4000W2x5000W
Frequenty Response20Hz-20kHz±0.5dB
THD+N:1KHz0.10%
Signal Noise Ration(dB)110dB
Input Impedance20KΩ Balanced / 10kΩ Unbalanced
Output ConnectorsSpeakon Connectors(NEUTRIK)
Power Requirement ( 50-60Hz )75V-135V or155-265V
ENTERNET functionYes
Dimension483×377×88mm
Weight(net)/(Gross Weight)13Kg (Net) / 18Kg (Gross Weight )

Product description

The supplier lists this product as Professional Amplifier. Its stated application is KTV, Bar, Disco. The listed model is DSP6KQ. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: DSP6KQ. 8ω Stereo Power(RMS): 4X900W. 4ω Stereo Power(RMS): 4X1600W. 2ω Stereo Power(RMS): 4X2000W. MODEL: DSP6KQ. Frequency Response: ±0.25dB,20Hz --- 20KHz. Signal to noise ratio: >110dB. Frequency: 20Hz---20KHz,Slope:12,18,24 or 48 dB/octave. to 36 oct,Frequency: 20Hz to 20KHz,.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 2000W 110V DSP6kq DSP Professional Audio 220V Power Amplifier with?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 2000W 110V DSP6kq DSP Professional Audio 220V Power Amplifier with cost?

The published price is US$700.00 – 750.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
