2452h 4″ Hf Neodymium Tweeter Speaker Unit
- Impedance
- 8 Ohms
- Frequency Response
- 500Hz
- Sensitivity
- 110dB Spl
- Application
- Commercial
- Noise
- <95dB
- Hi-Fi
- Hi-Fi
Specifications
| Product name | 2452h 4″ Hf Neodymium Tweeter Speaker Unit |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Noise | <95dB |
| Hi-Fi | Hi-Fi |
| Model NO. | 2452H |
| Activity | Passive |
| Operation Mode | Wire / Remote Control |
| Speaker System | Mono |
| Speaker Material | Wood |
| Application | Commercial |
| Certification | CE |
| Monitor | No |
| THD | <0.005% |
| Voice Coil Diameter | 4 Inch Voice Coil |
| Exit Size | 1.5 Inch Exit |
| Impedance | 8 Ohms |
| Frequency Response | 500Hz |
| Power Capacity | 100W |
| Dimension | 165 mm X 94 mm |
| Speaker Diaphragm | Pure Titanium Diaphragm |
| Magnet Material | Neodymium Magnet |
| H.F. Aural Sweep Test | 2.83V Input |
| Sensitivity | 110dB Spl |
| Transport Package | Carton Case |
| Specification | 1PCS/CTN |
| Origin | Guangzhou, China |
| HS Code | 8518210000 |
| Production Capacity | 200PCS/Month |
| Package Size | 32.00cm * 29.00cm * 16.00cm |
| Package Gross Weight | 6.000kg |
| Specification of the 2452H neodymium tweeter speaker unit | 2452H neodymium tweeter unit SPECIFICATIONS |
| Nominal Impedance | 8 ohm |
| High Frequency Transducer | 38 mm (1-1/2 in Exit) Pure Titanium Diaphragm |
| DC Resistance | 4.1 ohm ± 8% Aluminum Wire |
| Dimensions | 165 mm DIA x 94 mm D |
| Shipping Weight | 10 lbs. (4.5 kg.) |
| Our advantages & service | 1. Reply your enquiry in 24 working hours. |
| Customers' good feedback | Loading |
| Welcome to visit our website | skytoneaudio.en.made-in-china.com |
| Price | US$85.00 20 Pieces(MOQ) |
| Supplier | Guangzhou Skytone Audio Co., Limited |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Wood |
|---|---|
| Voice Coil Diameter | 4 Inch Voice Coil |
| Exit Size | 1.5 Inch Exit |
| Power Capacity | 100W |
| Magnet Material | Neodymium Magnet |
| Impedance | 8 Ohms |
Additional data
| 2452H neodymium tweeter unit SPECIFICATIONS | |
|---|---|
| ACOUSTIC & ELECTRICAL SPECIFICATIONS: | |
| Nominal Impedance: | 8 ohm |
| Power Capacity: | 100 Watts Continuous Program Above 500Hz 150 Watts Continuous Program Above 1 kHz |
| Frequency Response: | 500 Hz or Higher, 12 dB Octave Min. |
| Sensitivity: | 111 dB SPL* (1W @ 1m) On Axis On Horn 118 dB SPL** (1mW) On Plane Wave Tube |
| Crossover Freq.: | N/A |
| SYSTEM COMPONENTS: | |
| Cabinet: | N/A |
| Grille: | N/A |
| High Frequency Transducer: | 38 mm (1-1/2 in Exit) Pure Titanium Diaphragm |
| DC Resistance: | 4.1 ohm ± 8% Aluminum Wire |
| AURAL SWEEP TEST SPECIFICATIONS: | |
| H.F. Aural Sweep Test: | 2.83V Input, 100 Hz to 1.0 kHz |
| PHYSICAL SPECIFICATIONS: | |
| Dimensions: | 165 mm DIA x 94 mm D (6.5 DIA x 3.75 in. D) |
| Neodymium Magnet | |
| Shipping Weight: | 10 lbs. (4.5 kg.) |
Product description
The supplier lists this product. Its stated application is Commercial. The listed model is 2452H. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: 2452H. Speaker Material: Wood. Impedance: 8 Ohms. Frequency Response: 500Hz. Power Capacity: 100W. Magnet Material: Neodymium Magnet. Sensitivity: 110dB Spl. Nominal Impedance: 8 ohm. High Frequency Transducer: 38 mm (1-1/2 in Exit) Pure Titanium Diaphragm.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 2452h 4″ Hf Neodymium Tweeter Speaker Unit?
The listed minimum order quantity is 20 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 2452h 4″ Hf Neodymium Tweeter Speaker Unit cost?
The published price is US$85.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
