2452h Neodymium Magnet Speaker Driver, Neodymium Tweeter
Speaker Drivers, Woofers & Tweeters

2452h Neodymium Magnet Speaker Driver, Neodymium Tweeter

Model: 2452H Customization available Speaker Parts & Accessories
US$99.00
MOQ 2 Pieces
Frequency Response
500 Hz
Sensitivity
109dB SPL* (1W @ 1m)
Application
Commercial
Activity
Speaker Driver
Operation Mode
Speaker Driver
Speaker System
Optional Combination
Send Inquiry Full specifications

Specifications

Product name2452h Neodymium Magnet Speaker Driver, Neodymium Tweeter
CategorySpeaker Drivers, Woofers & Tweeters
Model NO.2452H
ActivitySpeaker Driver
Operation ModeSpeaker Driver
Speaker SystemOptional Combination
Speaker MaterialSpeaker Driver
ApplicationCommercial
CertificationCE, RoHS
MonitorNon
THD<0.005%
Model Number2452h
Nominal Impedance8 Ohm
Power Capacity100 Watts
Frequency Response500 Hz
High Frequency Transducer38 mm
Dimensions165 mm Dia X 94 mm D
Transport PackageCarton Case
Specification1PCS/CTN
OriginGuangzhou, China
HS Code8518210000
Production Capacity200PCS/Month
Package Size31.00cm * 28.00cm * 15.00cm
Package Gross Weight6.000kg
CustomizationAvailable
Noise<95dB
Hi-FiNot Hi-Fi
Sensitivity109dB SPL* (1W @ 1m)
DC Resistance4.1 ohm ± 8% Aluminum Wire
H.F. Aural Sweep Test2.83V Input, 100 Hz to 1.0 kHz
Shipping Weight10 lbs. (4.5 kg.)
Customer feedbackLoading containers
PriceUS$99.00 2 Pieces (MOQ)
SupplierGuangzhou Skytone Audio Co., Limited
Data retrieved2026-10-23

Available options

Speaker MaterialSpeaker Driver
Model Number2452h
Power Capacity100 Watts
Nominal Impedance8 Ohm
Customer feedbackLoading containers

Additional data

2452H SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
Nominal Impedance:8 ohm
Power Capacity:280W continuous program power capacity
Frequency Response:500 Hz or Higher, 12 dB Octave Min.
Sensitivity:109dB SPL* (1W @ 1m)
Crossover Freq.:N/A
SYSTEM COMPONENTS:
Cabinet:N/A
Grille:N/A
High Frequency Transducer:38 mm (1-1/2 in Exit) Pure Titanium Diaphragm
DC Resistance:4.1 ohm ± 8% Aluminum Wire
AURAL SWEEP TEST SPECIFICATIONS:
H.F. Aural Sweep Test:2.83V Input, 100 Hz to 1.0 kHz
PHYSICAL SPECIFICATIONS:
Dimensions:165 mm DIA x 94 mm D (6.5 DIA x 3.75 in. D)
Neodymium Magnet
Shipping Weight:10 lbs. (4.5 kg.)

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is 2452H. The specifications below reflect the information publicly displayed on the listing. Model NO.: 2452H. Speaker Material: Speaker Driver. Model Number: 2452h. Nominal Impedance: 8 Ohm. Power Capacity: 100 Watts. Frequency Response: 500 Hz. High Frequency Transducer: 38 mm. Noise: <95dB. Sensitivity: 109dB SPL* (1W @ 1m).

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 2452h Neodymium Magnet Speaker Driver, Neodymium Tweeter?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 2452h Neodymium Magnet Speaker Driver, Neodymium Tweeter cost?

The published price is US$99.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
