25mm High Frequency Driver Tweeter Speaker
Speaker Drivers, Woofers & Tweeters

25mm High Frequency Driver Tweeter Speaker

Model: DIV-5160 Customization available Speaker Parts & Accessories
Price on request
MOQ 3,000 Pieces
Material
Iron
Type
Speaker
Color
Black
After-sales Service
Asm
Warranty
One Year
Speaker Design
Tweeter
Send Inquiry Full specifications

Specifications

Product name25mm High Frequency Driver Tweeter Speaker
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
After-sales ServiceAsm
WarrantyOne Year
Model NO.DIV-5160
TypeSpeaker
Speaker DesignTweeter
ShapeSpiral
MaterialIron
Voltage12V
Connection ModeSingle Wire
ColorBlack
BrandAsm
Basket MaterialIron
for The CrowdYouth,Elderly,Chilren
Transport PackageStandard Export Packing
Specification25mm High Frequency Driver tweeter speaker
OriginZhejiang China
Production Capacity10000PCS/Month
Model NoDIV-5160
Throat Diameter1in(25mm)
Mounting TypeScrew on 1-3/8" or Bolt-On
Nominal Impedance8 Ohm
D. C Resistance7.0 Ohm
Power Capacity80Watts RMS
Sensitivity(1W/1M)108dB (Driver mounted on JC H-613 horn)
Frequency Range1.0KHz-20KHz
Recommended Crossover1.8KHz or Higher(12dB/oct. Minimum)
Diaphragm MaterialTitanium
Voice Coil Diameter2.03 in(51.6mm)
Voice Coil FormerKapton
Voice Coil MaterialRound&Ribbon Aluminum Wire
Flux Density1.75T
MagnetStrontium Ferrite
PriceNegotiable 3,000 Pieces(MOQ)
SupplierNingbo ASM Electronics Technology Co., Ltd.
Data retrieved2026-10-23

Available options

MaterialIron
Voltage12V
ColorBlack
Basket MaterialIron
Throat Diameter1in(25mm)
Nominal Impedance8 Ohm

Additional data

Nominal Impedance8Ohm
Power Capacity80Watts RMS
Frequency Range1.0KHz-20KHz

Product description

The supplier lists this product as Speaker. The listed model is DIV-5160. The specifications below reflect the information publicly displayed on the listing. Model NO.: DIV-5160. Material: Iron. Basket Material: Iron. Model No: DIV-5160. Nominal Impedance: 8 Ohm. Power Capacity: 80Watts RMS. Sensitivity(1W/1M): 108dB (Driver mounted on JC H-613 horn). Frequency Range: 1.0KHz-20KHz. Diaphragm Material: Titanium. Voice Coil Material: Round&Ribbon Aluminum Wire.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 25mm High Frequency Driver Tweeter Speaker?

The listed minimum order quantity is 3,000 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 25mm High Frequency Driver Tweeter Speaker cost?

The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
