25mm Vc High Frequency Ferrite Compression Driver
Speaker Drivers, Woofers & Tweeters

25mm Vc High Frequency Ferrite Compression Driver

Model: 25T25-8PF Customization available Speaker Parts & Accessories
US$7.00100–299 Pieces
US$6.50300–499 Pieces
US$6.00500+ Pieces
MOQ 100 Pieces
Application
Professional Audio
Noise
≥105dB
Hi-Fi
PA
Activity
Compatible
Operation Mode
Compatible
Speaker System
Compatible
Send Inquiry Full specifications

Specifications

Product name25mm Vc High Frequency Ferrite Compression Driver
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
Noise≥105dB
Hi-FiPA
Model NO.25T25-8PF
ActivityCompatible
Operation ModeCompatible
Speaker SystemCompatible
Speaker MaterialCompatible
ApplicationProfessional Audio
MonitorCompatible
THDCompatible
AES Power HandlingAES Power Handling
Voice Coil Diameter25.4mm
Diaphragm MaterialPolymer
Throat Diameter25.4mm (1in)
Transport PackageCarton
Specificationferrite, NW 0.79kg
OriginChina
HS Code85182900
Production Capacity50000pieces/Year
Package Size41.50cm * 30.70cm * 15.00cm
Package Gross Weight19.000kg
Lead Time7 days (1 - 30 Pieces) To be negotiated ( > 30 Pieces)
KEY FEATURES107dB 1W/1m sensitivity
NOTES1
Our quality management system is certified under ISO 90012015, and we hold multiple invention patents.
PriceUS$7.00 100-299 Pieces US$6.50 300-499 Pieces US$6.00 500+ Pieces
SupplierDongguan Weijiasheng Technology Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialCompatible
AES Power HandlingAES Power Handling
Voice Coil Diameter25.4mm
Diaphragm MaterialPolymer
Throat Diameter25.4mm (1in)

Additional data

Part Number25T25-8PF
Throat Diameter25.4mm (1in)
Nominal Impedance8Ω
Minimum Impedance6.6Ω at 4800Hz
AES Power Handling220W
Maximum Power Handling340W
(1W/1m) Sensitivity (1W/1m)4107dB
Recommended Crossover52.5kHz
Frequency Range1.5kHz-20kHz
Voice Coil Diameter25.4mm
Winding MaterialAluminum
Former MaterialKapton
Flux Density1.55T
Diaphragm MaterialPolymer
Phase Plug MaterialPlastic
Cover MaterialPlastic
Magnet MaterialFerrite
Net Weight0.79kg

Product description

The supplier lists this product. Its stated application is Professional Audio. The listed model is 25T25-8PF. The specifications below reflect the information publicly displayed on the listing. Noise: ≥105dB. Model NO.: 25T25-8PF. Speaker Material: Compatible. AES Power Handling: AES Power Handling. Diaphragm Material: Polymer.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 25mm Vc High Frequency Ferrite Compression Driver?

The listed minimum order quantity is 100 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 25mm Vc High Frequency Ferrite Compression Driver cost?

The published price is US$6.00 – 7.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
