2CH Active Line Array Speaker Amplifier Module with DSP Function
- Type
- Professional Amplifier
- Usage
- KTV, Bar, Disco
- Used For
- Professional
- Tube Type
- Transistor Amplifier
- Function
- Amplifier Combined
- Sound Channel
- 2
Specifications
| Product name | 2CH Active Line Array Speaker Amplifier Module with DSP Function |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Type | Professional Amplifier |
| Usage | KTV, Bar, Disco |
| Model NO. | AM5002 |
| Used For | Professional |
| Tube Type | Transistor Amplifier |
| Function | Amplifier Combined |
| Sound Channel | 2 |
| Output Number | 2 |
| Voltage | 110V or 220V |
| Element Number | Push-Pull Amplifier |
| Conductive Mode | D |
| 8ω Stereo Power(RMS) | 2×500W |
| 4ω Stereo Power(RMS) | 2×900W |
| Protection | Short Circuit DCP, Ovp, Uvp, Ocp, Otp |
| DSP Function | Mute, Polarity, Gain, Delay, Limiter, EQ, X-Over |
| DSP Control | USB and RS-485 |
| Net Weight | 3.6kg |
| Gross Weight | 5.5kg |
| Warranty | 2 Years |
| Transport Package | Durable Carton Box |
| Specification | 477x152x105mm |
| Origin | China |
| HS Code | 8518400000 |
| Production Capacity | 2000 Pieces/Month |
| Package Size | 39.00cm * 35.00cm * 21.00cm |
| Package Gross Weight | 6.000kg |
| Class | D |
| The module incorporates comprehensive DSP features | gain, mute, polarity, delay, limiter, parametric EQ and crossover. Remote PC control via USB or RS-485 enables precision tuning—perfect for system integrators who require fine adjustment in active speaker amplification. |
| Active Loudspeaker Cabinets | Ideal for OEM active speaker designs where two channels of high output are required—such as full-range plus subwoofer or dual-mid driver configurations. |
| Line Array or Column Speaker Systems | Suitable for use in line array modules where compact size, high power and DSP flexibility are key. |
| Portable PA & Touring Systems | With its lightweight structure and high output, it fits well in mobile PA setups, rental speakers, stage monitors and event gear. |
| Fixed Installations | Great for integration in installations like theatres, houses of worship, clubs, or conference venues where stable, high-power amplification and remote DSP control are valued. |
| The delivery time | it is 8-10 days if by air; it is 45-60 days if by sea. |
| Price | US$235.00 2-19 Pieces US$230.00 20+ Pieces |
| Supplier | Ascsonic Audio Technology Co., Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | 110V or 220V |
|---|---|
| 8ω Stereo Power(RMS) | 2×500W |
| 4ω Stereo Power(RMS) | 2×900W |
Additional data
| Model Name | AM5002 |
|---|---|
| 8Ω Stereo Power | 2×500W |
| 4Ω Stereo Power | 2×900W |
| Frequency Response | 20Hz-20KHz ±1dB |
| THD+N 1KHz 1W 8Ω | <0.1% |
| Signal to Noise Ratio 1KHz | >109dB |
| Channel Separation 1KHz | >70dB |
| Class | Class: D |
| Protection | Short Circuit DCP, OVP, UVP, OCP, OTP |
| Operating Voltage | 110V version: 90V-135V / 220V version: 180V-265V |
| Input Sensitivity | 1V |
| Input Impedance | 20KΩ |
| DSP Function | MUTE, Polarity, Gain, Delay, Limiter, EQ, X-Over |
| DSP Control | USB and RS-485 |
| Dimensions(W×H×D) mm | 477*152*105 |
| Net Weight(kg) | 3.6kg |
| Gross Weight(kg) | 5.5KG |
Product description
The supplier lists this product as Professional Amplifier. Its stated application is KTV, Bar, Disco. The listed model is AM5002. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: AM5002. 8ω Stereo Power(RMS): 2×500W. 4ω Stereo Power(RMS): 2×900W.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 2CH Active Line Array Speaker Amplifier Module with DSP Function?
The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 2CH Active Line Array Speaker Amplifier Module with DSP Function cost?
The published price is US$230.00 – 235.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
AM5002 · US$230.00 – 235.00 · MOQ 2 Pieces
