3” Ferrite High Frequency Compression Driver Professional Loudspeaker.
Speaker Drivers, Woofers & Tweeters

3” Ferrite High Frequency Compression Driver Professional Loudspeaker.

Model: DE7220T Customization available Speaker Parts & Accessories
US$12.00 – 32.00
MOQ 4 Pieces
Impedance
8 Ohm
Sensitivity
108dB
Application
Stage
Activity
Passive
Operation Mode
No
Speaker Material
Plastic
Send Inquiry Full specifications

Specifications

Product name3” Ferrite High Frequency Compression Driver Professional Loudspeaker.
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
ActivityPassive
Model NO.DE7220T
Operation ModeNo
Speaker MaterialPlastic
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating110 W
Program Power220 W
Frequency Range500-18000Hz
Sensitivity108dB
Voice Coil3''vc
Coil MaterialAluminum
Former MaterialKapton
Diaphragm MaterialTitanium
Impedance8 Ohm
MagnetFerrite
Transport PackageCarton
Specification380 x 370 x 90 mm
OriginChina
HS Code8518290000
Production Capacity50000
PriceUS$12.00-32.00 4 Pieces(MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

Speaker MaterialPlastic
AES Power Rating110 W
Program Power220 W
Coil MaterialAluminum
Former MaterialKapton
Diaphragm MaterialTitanium

Additional data

Throat diametermm(in.)36(1.4)
Nominal impedanceΩ8
DC resistanceRe Ω6
Program power (1)W220
AES Power rating(2)W110
Sensitivity (3)dB108
Frequency rangeHz500 ~ 18000
Voice coil diametermm(in.)72(3)
Magnet materialFerrite
Magnet ODmm170
Coil materialALR
Former materialKapton
Diaphragm materialTitanium
Voice coil InductancemH0,09
Flux densityT1.7
Recommended crossover (4)Hz1200
Net weightKg4
Multipack size(4) (WxDxH)mm380 x 370 x 90
Multipack weightKg16.9(4PCS)

Product description

The supplier lists this product. Its stated application is Stage. The listed model is DE7220T. The specifications below reflect the information publicly displayed on the listing. Noise: 0. Model NO.: DE7220T. Speaker Material: Plastic. AES Power Rating: 110 W. Program Power: 220 W. Frequency Range: 500-18000Hz. Sensitivity: 108dB. Coil Material: Aluminum. Former Material: Kapton. Diaphragm Material: Titanium.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 3” Ferrite High Frequency Compression Driver Professional Loudspeaker.?

The listed minimum order quantity is 4 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 3” Ferrite High Frequency Compression Driver Professional Loudspeaker. cost?

The published price is US$12.00 – 32.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
