3 Inch Professional Audio Active Line Array Speaker Mini Column System
PA, Stage & Line-Array Speakers

3 Inch Professional Audio Active Line Array Speaker Mini Column System

Model: C-23 & C-12BA Customization available Speakers & Audio Systems
Price on request
MOQ 1 Piece
Impedance
4/16ohms Switch
Frequency Response
90Hz-20kHz
Sensitivity
92dB(2.83V/M)
Usage
Party, Mini Concert
Application
Commercial, Home
Noise
<95dB
Send Inquiry Full specifications

Specifications

Product name3 Inch Professional Audio Active Line Array Speaker Mini Column System
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
Noise<95dB
Hi-FiNot Hi-Fi
Model NO.C-23 & C-12BA
ActivityActive
Operation ModeButton Control
Speaker System2.0 Channel
Speaker MaterialWood
ApplicationCommercial, Home
CertificationCE, RoHS
MonitorLCD Screen
THD<0.005%
Frequency Response90Hz-20kHz
Impedance4/16ohms Switch
Long-Term Power(RMS)100W
Power Peak Handing200W/5min
Sensitivity92dB(2.83V/M)
UsageParty, Mini Concert
ControlWire/ Control
Connection2*Nl 4 Speakon
DriverNeodymium
Low Driver2*3 Inch
High Driver1*1.3 Inch
PassiveActive
Enclosure ConstructionAluminum
Cabinet Surface TreatmentBlack Painting
Transport PackageCarton
Specification283*107.7*111.8mm
OriginGuangzhou
HS Code8518220000
PriceNegotiable 1 Piece(MOQ)
SupplierGuangzhou Seer Audio Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialWood
Long-Term Power(RMS)100W
Power Peak Handing200W/5min
Impedance4/16ohms Switch

Additional data

ModelC-23
Frequency Response90Hz-20KHz
Directivity AngleH120°×V120°
Impedance4/16ohms Switch
Long-term Power(RMS)100W
Power peak handing200W/5Min
Sensitivity92dB(2.83V/m)
Maximum SPL110dB
Connection2×NL 4 speakon
Enclosure ConstructionAluminum
Cabinet Surface TreatmentBlack Painting
Dimensions(H×W×D)283×107.7×111.8mm
Low3 IN×2(75mm )
High1.3 IN×1(26.5mm )
N.W.3.1Kg
ColorBlack / White
ModelC-12BA
Frequency Response40Hz-250Hz
Impedance8ohms
Long-term Power(RMS)400W
Power peak handing800W/5Min
Sensitivity93dB(2.83V/m)
Maximum SPL118dB
Connection2×NL 4 speakon
Enclosure Construction18Birch Plywood
Cabinet Surface TreatmentBlack Catalyzed Polyurethane Paint
Dimensions(H×W×D)450×400×500mm
Low12 IN×1(310mm )
N.W.27.5Kg
Power220v/50Hz-60Hz

Product description

The supplier lists this product. Its stated application is Commercial, Home. The listed model is C-23 & C-12BA. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: C-23 & C-12BA. Speaker Material: Wood. Frequency Response: 90Hz-20kHz. Impedance: 4/16ohms Switch. Long-Term Power(RMS): 100W. Power Peak Handing: 200W/5min. Sensitivity: 92dB(2.83V/M). Driver: Neodymium. Low Driver: 2*3 Inch.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 3 Inch Professional Audio Active Line Array Speaker Mini Column System?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 3 Inch Professional Audio Active Line Array Speaker Mini Column System cost?

The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
