38mm Vc Neodymium High Spl Style Compression Driver /Tweeter
- Type
- Compression Driver
- Application
- Commercial
- Activity
- Passive
- Magnet
- Neodymium
- Phase Plug
- Plastic
- Diaphragm
- Pi
Specifications
| Product name | 38mm Vc Neodymium High Spl Style Compression Driver /Tweeter |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Activity | Passive |
| Application | Commercial |
| Model NO. | H2048-38N |
| Magnet | Neodymium |
| Phase Plug | Plastic |
| Diaphragm | Pi |
| Voice Coil | Ccar |
| Type | Compression Driver |
| Transport Package | Strong Carton |
| Specification | Shipping Weight (10unit) 6.5 kg |
| Origin | Guangzhou, China |
| HS Code | 8518290000 |
| Production Capacity | 4000/Month |
| https | //ruizhengsound.en.made-in-china.com/product/xKkmMTpOCFUS/China-12inch-Copper-Line-Array-Neodymium-MID-Bass-Audio-Speaker.html |
| Price | US$25.00-35.00 8 Pieces(MOQ) |
| Supplier | Foshan Ruizheng Audio Co.,Ltd |
| Data retrieved | 2026-10-23 |
Additional data
| MODEL H2048-38N | ||||
|---|---|---|---|---|
| Specifications | Thiele Small Parameters | |||
| TYPE | Compression driver | Fs | 1100 Hz | |
| Exit Throat Diameter | 25.4 mm/1 in | Re | 5.0 ohm | |
| Rated impedance | 8 ohm | Diaphragm Material | PI | |
| Nominal (AES) | 40 W | Suspension Material | PI | |
| Continuous Program | 80 W | Magnet | Neodymium | |
| Sensitivity(1w/1m) | 106 dB | Phase plug | Plastic | |
| Frequency Range | 1100Hz-19000Hz | |||
| Voice Coil Diameter | 38 mm/1.5 in | |||
| Voice Coil Material | CCAR outside | |||
| Mounting lnformation | Shipping lnformation | |||
| Overall Diameter | φ70 mm/φ2.8 in | Net Weight (1unit) | 0.6 kg | |
| Depth | 53 mm/2.1 in | Shipping Weight (10unit) | 6.5 kg | |
| Package Size (10unit) | 27x22x14cm |
Product description
The supplier lists this product as Compression Driver. Its stated application is Commercial. The listed model is H2048-38N. The specifications below reflect the information publicly displayed on the listing. Model NO.: H2048-38N.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 38mm Vc Neodymium High Spl Style Compression Driver /Tweeter?
The listed minimum order quantity is 8 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 38mm Vc Neodymium High Spl Style Compression Driver /Tweeter cost?
The published price is US$25.00 – 35.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
H2048-38N · US$25.00 – 35.00 · MOQ 8 Pieces
