3way Line Array 12inch Speaker Line Array System Line Array Box (K2)
PA, Stage & Line-Array Speakers

3way Line Array 12inch Speaker Line Array System Line Array Box (K2)

Model: K2 Customization available Speakers & Audio Systems
Price on request
MOQ 8 Pieces
Application
Commercial
Activity
Passive
Operation Mode
Button Control
Speaker System
Optional Combination
Speaker Material
Wood
Certification
Factory QC
Send Inquiry Full specifications

Specifications

Product name3way Line Array 12inch Speaker Line Array System Line Array Box (K2)
CategoryPA, Stage & Line-Array Speakers
Model NO.K2
ActivityPassive
Operation ModeButton Control
Speaker SystemOptional Combination
Speaker MaterialWood
ApplicationCommercial
CertificationFactory QC
THD<0.03%
Transport PackageFoam+Carton Packing
OriginChina
HS Code8518220000
Production Capacity3000pieces Per Month
CustomizationAvailable
Noise<95dB
Hi-FiNot Hi-Fi
Frequency Response(-10dB)60Hz-18kHz
Frequency Response(-3dB)65Hz-18kHz
Systen Input Power Rating1200W Continuous 2400W Peak
Max Calculated SPL134dB Cont 140dB Peak.
Horizontal Coverage≥
Vertical CoverageVertical coverage angle change according to the different quantity configuration .
LF Power Handing2x200W Cont., 800W Peak
MF Power Handing2x60W Cont., 240W Peak
HF Power Handing98/97/109 dB
Sensitivity(LF/MF/HF)450-650 Hz
LF to MF crossover Freq.1700Hz Passive or Active
MF to HF crossover Freq.2x12" ,8 ohms, Neodymium
LF Passband4x6.5" ,16 ohms, Neodymium
MF Passband2x2.5",16ohms, Neodymium
Neutrik2*EP8
Install Dim(HxWxD)70kg
PriceNegotiable 8 Pieces (MOQ)
SupplierGuangzhou VEMA Audio Equipment Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialWood
Systen Input Power Rating1200W Continuous 2400W Peak
LF Power Handing
2x200W Cont.800W Peak
MF Power Handing
2x60W Cont.240W Peak
HF Power Handing98/97/109 dB

Additional data

K2
K2 is a line array loudspeaker for long throw distance sound reinforcement.Using the K2 Flying Frame it can be flown in vertical columns with up to 16 cabinets.K2 is a Four-way design housing fitted with two 12"LF drivers,four 6.5"Mid drivers and Two HF 2.5" drivers.The cylindrical wave segments of each cabinet can couple without gaps coherently.angles between adjacent cabinets can be set in the range from 0° to 6°.
TYPECompact, Four-way passive
Frequency Response(-10dB):60Hz-18kHz
Frequency Response(-3dB):65Hz-18kHz
Systen Input Power Rating:1200W Continuous 2400W Peak
Max Calculated SPL:134dB Cont 140dB Peak.
Horizontal Coverage:≥100°
Vertical Coverage:Vertical coverage angle change according to the different quantity configuration .
2x350W Cont., 1400W Peak
LF Power Handing:2x200W Cont., 800W Peak
MF Power Handing:2x60W Cont., 240W Peak
HF Power Handing:98/97/109 dB
Sensitivity(LF/MF/HF):450-650 Hz
LF to MF crossover Freq.:1700Hz Passive or Active
MF to HF crossover Freq.:2x12" ,8 ohms, Neodymium
LF Passband:4x6.5" ,16 ohms, Neodymium
MF Passband:2x2.5",16ohms, Neodymium
HF Passband:Neutrik:2*EP8
Connectors:
Install Dim(HxWxD):70kg
Net Weight(Install):±1: LF(1)
Range Inputs:±2: LF(2)
±3: MF
±4: HF

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is K2. The specifications below reflect the information publicly displayed on the listing. Model NO.: K2. Speaker Material: Wood. Noise: <95dB. Frequency Response(-10dB): 60Hz-18kHz. Frequency Response(-3dB): 65Hz-18kHz. Systen Input Power Rating: 1200W Continuous 2400W Peak. LF Power Handing: 2x200W Cont., 800W Peak. MF Power Handing: 2x60W Cont., 240W Peak. HF Power Handing: 98/97/109 dB. Sensitivity(LF/MF/HF): 450-650 Hz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 3way Line Array 12inch Speaker Line Array System Line Array Box (K2)?

The listed minimum order quantity is 8 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 3way Line Array 12inch Speaker Line Array System Line Array Box (K2) cost?

The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
