44t25-8TFS 44mm Vc Ferrite Hf Compression Driver Titanium Diaphragm Compact Size
Crossovers, Voice Coils, Cones & Repair Parts

44t25-8TFS 44mm Vc Ferrite Hf Compression Driver Titanium Diaphragm Compact Size

Model: 44T25-8TFS Customization available Speaker Parts & Accessories
US$18.0050–99 Pieces
US$17.00100–499 Pieces
US$16.50500+ Pieces
MOQ 50 Pieces
Application
Professional Audio
Noise
≥105dB
Hi-Fi
PA
Activity
Compatible
Operation Mode
Compatible
Speaker System
Compatible
Send Inquiry Full specifications

Specifications

Product name44t25-8TFS 44mm Vc Ferrite Hf Compression Driver Titanium Diaphragm Compact Size
CategoryCrossovers, Voice Coils, Cones & Repair Parts
CustomizationAvailable
Noise≥105dB
Hi-FiPA
Model NO.44T25-8TFS
ActivityCompatible
Operation ModeCompatible
Speaker SystemCompatible
Speaker MaterialCompatible
ApplicationProfessional Audio
MonitorCompatible
THDCompatible
AES Power Handling50W
Voice Coil Diameter44.4mm
Diaphragm MaterialTitanium
Throat Diameter25.4mm (1in)
Transport PackageCarton
Specificationferrite, NW 1.53kg
OriginChina
HS Code85182900
Production Capacity50000pieces/Year
Package Size41.50cm * 30.00cm * 16.50cm
Package Gross Weight20.500kg
Lead Time7 days (1 - 30 Pieces) To be negotiated ( > 30 Pieces)
KEY FEATURES105dB 1W/1m sensitivity
NOTES1
Our quality management system is certified under ISO 90012015, and we hold multiple invention patents.
PriceUS$18.00 50-99 Pieces US$17.00 100-499 Pieces US$16.50 500+ Pieces
SupplierDongguan Weijiasheng Technology Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialCompatible
AES Power Handling50W
Voice Coil Diameter44.4mm
Diaphragm MaterialTitanium
Throat Diameter25.4mm (1in)

Additional data

Part Number44T25-8TFS
Throat Diameter25.4mm (1in)
Nominal Impedance8Ω
Minimum Impedance7.4Ω at 3500Hz
AES Power Handling250W
Maximum Power Handling3100W
(1W/1m) Sensitivity (1W/1m)4105dB
Recommended Crossover51.5kHz
Frequency Range1.0kHz-18kHz
Voice Coil Diameter44.4mm
Winding MaterialFlat Aluminum
Former MaterialKapton
Flux Density1.5T
Diaphragm MaterialTitanium
Phase Plug MaterialPlastic
Cover MaterialCast Aluminum
Magnet MaterialFerrite
Net Weight1.53kg

Product description

The supplier lists this product. Its stated application is Professional Audio. The listed model is 44T25-8TFS. The specifications below reflect the information publicly displayed on the listing. Noise: ≥105dB. Model NO.: 44T25-8TFS. Speaker Material: Compatible. AES Power Handling: 50W. Diaphragm Material: Titanium.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 44t25-8TFS 44mm Vc Ferrite Hf Compression Driver Titanium Diaphragm?

The listed minimum order quantity is 50 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 44t25-8TFS 44mm Vc Ferrite Hf Compression Driver Titanium Diaphragm cost?

The published price is US$16.50 – 18.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
