6 Inches Aluminum Horn Tweeter (DE-5107TH-2)
Speaker Drivers, Woofers & Tweeters

6 Inches Aluminum Horn Tweeter (DE-5107TH-2)

Model: DE-5107TH-2 Customization available Speaker Parts & Accessories
US$18.00
MOQ 100 Pieces
Sensitivity
108dB
Application
Commercial, Home
Noise
≥105dB
Hi-Fi
Hi-Fi
Activity
Passive
Operation Mode
Wire / Remote Control
Send Inquiry Full specifications

Specifications

Product name6 Inches Aluminum Horn Tweeter (DE-5107TH-2)
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
Noise≥105dB
Hi-FiHi-Fi
Model NO.DE-5107TH-2
ActivityPassive
Operation ModeWire / Remote Control
Speaker System2.1 Channel
Speaker MaterialMetal
ApplicationCommercial, Home
CertificationCE, RoHS
MonitorVFD Screen
THD<0.005%
Normal Impedance8ohms
Power Capacity80watt RMS
Sensitivity108dB
Frequency Range1.0Hz-20kHz
Diaphragm MaterialTitanium
Flux Density1.75t
MagnetStrontium Ferrite
Transport PackageStandard Epxort Carton
Specification6 inches
OriginNingbo China
HS Code8518290000
Production Capacity50, 000PCS/Month
Package Size50.00cm * 50.00cm * 60.00cm
Package Gross Weight20.000kg
Lead Time15 days (1 - 500 Pieces) To be negotiated ( > 500 Pieces)
Throat Diameter2 inches (50mm), optimized for high-frequency horn loading.
Nominal Impedance8 Ohm with D.C. resistance of 7.0 Ohm, compatible with standard professional amplifiers.
Recommended Crossover1.8 kHz or higher at 12dB/octave minimum, ensuring clean signal separation.
DiaphragmTitanium material provides excellent stiffness-to-weight ratio, minimizing distortion at high SPL levels.
Voice Coil2.03-inch (51.6mm) diameter with Kapton former, wound with round and ribbon aluminum wire for superior heat dissipation and fast transient response.
Magnetic CircuitStrontium Ferrite Y35 magnet generating a flux density of 1.75 T, delivering strong driving force and dynamic range.
ApplicationsTouring sound systems, high-output stage monitors, fixed installation loudspeakers, and professional horn-loaded enclosures.
PriceUS$18.00 100 Pieces(MOQ)
SupplierNinghai County Chalu Jinbaili Daily Necessities Store
Data retrieved2026-10-23

Available options

Speaker MaterialMetal
Power Capacity80watt RMS
Diaphragm MaterialTitanium
Normal Impedance8ohms
Throat Diameter2 inches (50mm), optimized for high-frequency horn loading.
Nominal Impedance8 Ohm with D.C. resistance of 7.0 Ohm, compatible with standard professional amplifiers.

Additional data

ModelDE-5107TH-2
Throat Diameter2 in (50mm)
Nominal Impedance8 Ohm
D.C Resistance7.0 Ohm
Power Capacity80 Watts RMS
Sensitivity (1W/1M)108 dB (mounted on JC H-613 horn)
Frequency Range1.0 kHz - 20 kHz
Recommended Crossover1.8 kHz or Higher (12dB/oct. minimum)
Diaphragm MaterialTitanium
Voice Coil Diameter2.03 in (51.6 mm)
Voice Coil FormerKapton
Voice Coil MaterialRound & Ribbon Aluminum Wire
Flux Density1.75 T
MagnetStrontium Ferrite Y35

Product description

The supplier lists this product. Its stated application is Commercial, Home. The listed model is DE-5107TH-2. The specifications below reflect the information publicly displayed on the listing. Noise: ≥105dB. Model NO.: DE-5107TH-2. Speaker Material: Metal. Normal Impedance: 8ohms. Power Capacity: 80watt RMS. Sensitivity: 108dB. Frequency Range: 1.0Hz-20kHz. Diaphragm Material: Titanium. Nominal Impedance: 8 Ohm with D.C. resistance of 7.0 Ohm, compatible with standard professional amplifiers..

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 6 Inches Aluminum Horn Tweeter (DE-5107TH-2)?

The listed minimum order quantity is 100 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 6 Inches Aluminum Horn Tweeter (DE-5107TH-2) cost?

The published price is US$18.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
