6C Low Smoke Zero Halogen CPR Dca Multi-conductor-audio,control.& Instrumentation Alarm Cables
AUX, Analog & Interconnect Cables

6C Low Smoke Zero Halogen CPR Dca Multi-conductor-audio,control.& Instrumentation Alarm Cables

Model: CPR Customization available Cables, Adapters & Audio Electronics
US$0.03
MOQ 10,000 Meters
Application
Alarm Cable
Material Shape
Round Wire
Conductor Type
Stranded
Wire Core Material
Bare Copper Wire
Certification
CE, ISO, RoHS, CCC, VDE
Cable Core
2/4/6/8/10/12/14/16/18/20cores
Send Inquiry Full specifications

Specifications

Product name6C Low Smoke Zero Halogen CPR Dca Multi-conductor-audio,control.& Instrumentation Alarm Cables
CategoryAUX, Analog & Interconnect Cables
Model NO.CPR
Material ShapeRound Wire
Conductor TypeStranded
Wire Core MaterialBare Copper Wire
CertificationCE, ISO, RoHS, CCC, VDE
Cable Core2/4/6/8/10/12/14/16/18/20cores
ShieldAl/Foil
Drain Wire7*0.2mm
JacketPVC
Transport PackageShipping Box or Wooden Pallet
Specification2/4/6/8/10/12/14/16/18/20 cores
OriginNingbo
Production Capacity5000000000
Package Size32.00cm * 32.00cm * 10.00cm
Package Gross Weight20.000kg
CustomizationAvailable
ApplicationAlarm Cable
Cover MaterialPVC
Structure24AWG(0.22mm2) unshielded or shiel
Conductors MaterialsTC/BC/CCA/TCCA/TCCAM
InsulationPVC/LSF/LSZH/LSOH/LSNH
Rip cordNylon Fiber
Voltage Test1500Vcc/min
Minimum insulation resistance at 20ºC1500MΩ.km
Mutual capacity of the pairs<57.5nf>
QUALITY POLICYExactcables
PriceUS$0.03 10,000 Meters (MOQ)
SupplierNINGBO EXACT CABLES & WIRE CO., LTD.
Data retrieved2026-10-23

Available options

Material ShapeRound Wire
Wire Core MaterialBare Copper Wire
Cover MaterialPVC
Conductors MaterialsTC/BC/CCA/TCCA/TCCAM
Voltage Test1500Vcc/min
Mutual capacity of the pairs<57.5nf>

Additional data

Part N0.DescriptionItemConductor Spec.InsulationJacketPacking
Nom Thick. (mm)Nom Diam (mm)Nom Thick. (mm)Nom Diam (mm)
ECAC001TC or BC or CCA or TCCA or TCCAM, Screened or Unscreened; Rip cord or NO. Drain wire or NO.2x0.22 mm22×7/0.20.221.050.453.1Box Coil DrumPaper reel Plastic reel Wooden reel
ECAC0024x0.22 mm24×7/0.20.221.050.453.4
ECAC0036x0.22 mm26×7/0.20.221.050.54.1
ECAC0048x0.22 mm28×7/0.20.221.050.54.5
ECAC00510x0.22 mm210×7/0.20.221.050.65.1
ECAC00612x0.22 mm212×7/0.20.221.050.65.5
ECAC00714x0.22 mm214×7/0.20.221.050.76.1
ECAC00816x0.22 mm216×7/0.20.221.050.76.4
ECAC00920x0.22 mm220×7/0.20.221.050.87.2

Product description

The supplier lists this product. Its stated application is Alarm Cable. The listed model is CPR. The specifications below reflect the information publicly displayed on the listing. Model NO.: CPR. Material Shape: Round Wire. Wire Core Material: Bare Copper Wire. Cover Material: PVC. Conductors Materials: TC/BC/CCA/TCCA/TCCAM.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 6C Low Smoke Zero Halogen CPR Dca Multi-conductor-audio,control.&?

The listed minimum order quantity is 10,000 meters. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 6C Low Smoke Zero Halogen CPR Dca Multi-conductor-audio,control.& cost?

The published price is US$0.03 per meter. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
