721042 Professional Audio Mini 4/7 Channel Sound Analog Mixer with Delay, Digital Effect, USB, One Output and One Return for PA System
Speaker Amplifiers & Audio Processors

721042 Professional Audio Mini 4/7 Channel Sound Analog Mixer with Delay, Digital Effect, USB, One Output and One Return for PA System

Model: 721042 Customization available Cables, Adapters & Audio Electronics
US$9.90 – 39.90
MOQ 10 Pieces
Frequency Response
20Hz -20kHz ± 0.5dB
Application
Home, Commercial, Broadcast
The Maximum Output Level
+26 Dbu
Main Level Meter
5 Segment LED
Common Mode Rejection Ratio (Mic 1kHz)
<0.01% (Channel Input to Mix Output)
Crosstalk (1K Hz)
> 85 dB
Send Inquiry Full specifications

Specifications

Product name721042 Professional Audio Mini 4/7 Channel Sound Analog Mixer with Delay, Digital Effect, USB, One Output and One Return for PA System
CategorySpeaker Amplifiers & Audio Processors
Model NO.721042
The Maximum Output Level+26 Dbu
Main Level Meter5 Segment LED
Frequency Response20Hz -20kHz ± 0.5dB
Common Mode Rejection Ratio (Mic 1kHz)<0.01% (Channel Input to Mix Output)
Crosstalk (1K Hz)> 85 dB
Stereo TrsNon-Balanced, Tip Hot 10kohm, Sensitivity -40 to +
L / R Output TrsUnbalanced, Tip Hot End, <75 Ohm, -2dbu, Max + 18d
Fx / Aux Output TrsUnbalanced, Tip Hot Side, <75 Ohm, -2dbu, Max + 18
Headphones Trs,Tip L, Ring R, Recommended 30 to 600 Ohm Headphone
Maximum Power Input Power15 W
Dimension4channel
Transport PackageCarton
Specification32*26*8 cm; 2 kg
OriginChina
HS Code8543709990
Production Capacity>500000
CustomizationAvailable
ApplicationHome, Commercial, Broadcast
Game FunctionWithout Game Function
SpecificationsModel
PriceUS$9.90-39.90 10 Pieces (MOQ)
SupplierGuangzhou strong sound electronic equipment Co., Ltd
Data retrieved2026-10-23

Available options

Maximum Power Input Power15 W

Additional data

Model721042
Maximum input levelMicrophone + 24dBu
Line + 24dB
The maximum output level+26 dBu
Main level meter5 segment LED
Frequency response20Hz -20Khz ± 0.5db
Common mode rejection ratio (MIC 1Khz)> 75 dB
Total harmonic distortion (THD + N)<0.01% (channel input to mix output)
Crosstalk (1K Hz)> 85 dB
Noise (22Hz - 22K Hz)Equivalent input noise -116dBu
Remaining output noise <-80 dBu
Mono / Stereo Channel EQHigh Frequency, Broth, ± 15dB, 12K Hz
High frequency, peak and valley type, ± 15dB, 2.5K Hz
Low frequency, broom type, ± 15dB, 80Hz
Mono XLRbalanced, 2-pin hot end, 2K ohm, sensitivity -60 to +14 dBu
TRS balanced, tip hot 10Kohm, sensitivity -40 to +14 dBu
XLR Phantom Power + 48V
Stereo TRSnon-balanced, tip hot 10Kohm, sensitivity -40 to +14 dBu
L / R output TRSunbalanced, tip hot end, <75 ohm, -2dBu, max + 18dBu
FX / AUX output TRSunbalanced, tip hot side, <75 ohm, -2dBu, max + 18dBu
Headphones TRS,tip L, ring R, recommended 30 to 600 ohm headphones
Maximum power input power15 W
Dimension4channel
Width210mm
Depth230mm
Height37mm

Product description

The supplier lists this product. Its stated application is Home, Commercial, Broadcast. The listed model is 721042. The specifications below reflect the information publicly displayed on the listing. Model NO.: 721042. Frequency Response: 20Hz -20kHz ± 0.5dB. Maximum Power Input Power: 15 W.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 721042 Professional Audio Mini 4/7 Channel Sound Analog Mixer with?

The listed minimum order quantity is 10 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 721042 Professional Audio Mini 4/7 Channel Sound Analog Mixer with cost?

The published price is US$9.90 – 39.90 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
