75mm Vc High Frequency Ferrite Compression Driver Titanium&Polymer Diaphragm
Crossovers, Voice Coils, Cones & Repair Parts

75mm Vc High Frequency Ferrite Compression Driver Titanium&Polymer Diaphragm

Model: VA82-8 Customization available Speaker Parts & Accessories
US$40.0050–99 Pieces
US$38.00100–499 Pieces
US$36.00500+ Pieces
MOQ 50 Pieces
Application
Professional Audio
Noise
107dB
Hi-Fi
PA
Activity
Compatible
Operation Mode
Compatible
Speaker System
Compatible
Send Inquiry Full specifications

Specifications

Product name75mm Vc High Frequency Ferrite Compression Driver Titanium&Polymer Diaphragm
CategoryCrossovers, Voice Coils, Cones & Repair Parts
CustomizationAvailable
Noise107dB
Hi-FiPA
Model NO.VA82-8
ActivityCompatible
Operation ModeCompatible
Speaker SystemCompatible
Speaker MaterialCompatible
ApplicationProfessional Audio
CertificationCE, RoHS
MonitorCompatible
THDCompatible
AES Power Handling110W
Voice Coil Diameter74.55mm
Diaphragm MaterialPolymer&Titanium
Throat Diameter36mm (1.4in)
Transport PackageCarton
Specificationferrite, NW 4.5kg
OriginChina
HS Code85182900
Production Capacity50000pieces/Year
Package Size40.00cm * 37.50cm * 9.60cm
Package Gross Weight19.000kg
Lead Time7 days (1 - 30 Pieces) To be negotiated ( > 30 Pieces)
KEY FEATURES107dB 1W/1m sensitivity
NOTES1
Our quality management system is certified under ISO 90012015, and we hold multiple invention patents.
PriceUS$40.00 50-99 Pieces US$38.00 100-499 Pieces US$36.00 500+ Pieces
SupplierDongguan Weijiasheng Technology Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialCompatible
AES Power Handling110W
Voice Coil Diameter74.55mm
Diaphragm MaterialPolymer&Titanium
Throat Diameter36mm (1.4in)

Additional data

Part NumberVA82-8
Throat Diameter36mm (1.4in)
Nominal Impedance8Ω
Minimum Impedance8.0Ω at 3000Hz
AES Power Handling2110W
Maximum Power Handling3220W
(1W/1m) Sensitivity (1W/1m)4107dB
Recommended Crossover51.0kHz
Frequency Range500Hz-18kHz
Voice Coil Diameter74.55mm
Winding MaterialFlat Copper Clad Aluminum
Former MaterialKapton
Flux Density1.8T
Diaphragm MaterialPolymer&Titanium
Phase Plug MaterialPlastic
Cover MaterialCast Aluminum
Magnet MaterialFerrite
Net Weight4.5kg

Product description

The supplier lists this product. Its stated application is Professional Audio. The listed model is VA82-8. The specifications below reflect the information publicly displayed on the listing. Noise: 107dB. Model NO.: VA82-8. Speaker Material: Compatible. AES Power Handling: 110W. Diaphragm Material: Polymer&Titanium.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 75mm Vc High Frequency Ferrite Compression Driver Titanium&Polymer?

The listed minimum order quantity is 50 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 75mm Vc High Frequency Ferrite Compression Driver Titanium&Polymer cost?

The published price is US$36.00 – 40.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
