75ohm Rg 6 Computer Data Communication Audio Coaxial Cable
Optical & Digital Audio Cables

75ohm Rg 6 Computer Data Communication Audio Coaxial Cable

Model: 75ohm RG 6 coaxial cable Customization available Cables, Adapters & Audio Electronics
US$10.00100–999 Rolls
US$9.001,000–4,999 Rolls
US$8.005,000+ Rolls
MOQ 100 Rolls
Type
Coaxial
Application
DVD Player, Telephone, Game Player, Coaxial Cable
Color
Black
Species
Coaxial
Connector
RCA
Material Shape
Round Wire
Send Inquiry Full specifications

Specifications

Product name75ohm Rg 6 Computer Data Communication Audio Coaxial Cable
CategoryOptical & Digital Audio Cables
CustomizationAvailable
ApplicationDVD Player, Telephone, Game Player, Coaxial Cable
ColorBlack
Model NO.75ohm RG 6 coaxial cable
TypeCoaxial
SpeciesCoaxial
ConnectorRCA
Material ShapeRound Wire
Wire Core MaterialBare Copper Wire
CertificationRoHS, CE, ISO9001
BrandHanli
ConductorCopper/CCA
Diameter1.58mm
Cable Size10mm
ShieldSingle-Side Self-Adhesive
Transport Package200
Specification1/0.8CU+PE+B+PVC
OriginZhejiang
HS Code8544200000
Production Capacity10000000/Year
Package Size30.00cm * 30.00cm * 30.00cm
Package Gross Weight3.000kg
PriceUS$10.00 100-999 Rolls US$9.00 1,000-4,999 Rolls US$8.00 5,000+ Rolls
SupplierZhejiang Kuayue Cable Co., Ltd.
Data retrieved2026-10-23

Available options

ColorBlack
Material ShapeRound Wire
Wire Core MaterialBare Copper Wire
Diameter1.58mm
Cable Size10mm
ConnectorRCA

Additional data

Inner conductorPlain copperΦ1.0±0.025mm
DielectricF. PEΦ4.7±0.10mm
Outer conductorTinned copper112x0.13mm
Shield coverage95%
SheathPVC o rLSZHΦ7.00±0.10mm
Impedance53±3 Ohm0
Nominal capacitance94pF/m
Velocity of propagation66%
Insulation resistance>2000 Mohm.Km
Inner conductor resistance35.0 Ohm/Km
Outer conductorresistance16.5Ohm/Km
Test/Operatig Voltage(max)5KV/2KV
Operating temperaturerange-30°C-+70°C
Copper Weight18.7Kg/Km
Cable weight(approx.)39.9Kg/Km
Screening effectiveness100-900MHz>55dB
Frequency(MHz)Attenuation(dB/100m)Attenuation(dB/100ft)
509.12.77
10013.13.99
20019.45.91
40028.48.66
50032.29.82
60035.710.88
86044.813.66
100049.014.94
30-300MHz>26dB
300-600MHz>25dB
600-900MHz>24dB

Product description

The supplier lists this product as Coaxial. Its stated application is DVD Player, Telephone, Game Player, Coaxial Cable. The listed model is 75ohm RG 6 coaxial cable. The specifications below reflect the information publicly displayed on the listing. Model NO.: 75ohm RG 6 coaxial cable. Connector: RCA. Material Shape: Round Wire. Wire Core Material: Bare Copper Wire.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 75ohm Rg 6 Computer Data Communication Audio Coaxial Cable?

The listed minimum order quantity is 100 rolls. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 75ohm Rg 6 Computer Data Communication Audio Coaxial Cable cost?

The published price is US$8.00 – 10.00 per roll, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
