8′ ′ Waterproof Installation Speaker with 100V Transformer, IP46
- Rated Power
- 37.5W/75W/150W/off/16Ω
- Impedance
- 16 Ohms Nominal
- Sensitivity
- 94dB 1 Watt/1 Meter
- Type
- PRO-Audio
- Certification
- CE, RoHS
- Warranty
- 5years
Specifications
| Product name | 8′ ′ Waterproof Installation Speaker with 100V Transformer, IP46 |
|---|---|
| Category | Ceiling, Wall & Installation Speakers |
| Customization | Available |
| Certification | CE, RoHS |
| Warranty | 5years |
| Model NO. | ES108/ES108T |
| Type | PRO-Audio |
| Combination | PRO-Audio |
| Voltage | 100V |
| Format | PRO-Audio |
| Frequency Response(-3dB) | 60Hz-18kHz |
| Woofer | 1X8'(200mm)/2'' Voice Coil Lf |
| Driver | 1X1''(25mm)/1'' Voice Coil Hf |
| Rated Power | 37.5W/75W/150W/off/16Ω |
| Sensitivity | 94dB 1 Watt/1 Meter |
| Impedance | 16 Ohms Nominal |
| Maximum Spl | 116dB Continuous, 120dB Peak |
| Dispersion(-6dB) | 90°X50° |
| Crossover Frequencies | 2.3kHz Passive |
| Certificate | CE, RoHS, CCC, IP46 |
| Transport Package | Carton Box |
| Specification | 370x310x525mm/pc |
| Origin | Dongguan, China |
| HS Code | 8518220000 |
| Production Capacity | 5000PCS/Month |
| Applications | 1.Classroom |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Web | fdbaudiochina.en.made-in-china.com |
| Price | US$106.00-1,025.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | 100V |
|---|---|
| Rated Power | 37.5W/75W/150W/off/16Ω |
| Impedance | 16 Ohms Nominal |
Additional data
| FREQUENCY RESPONSE(-3dB) | 60Hz-18Khz |
|---|---|
| DRIVERS | 1x8'(200mm)/2'' voice coil LF |
| 1x1''(25mm)/1'' voice coil HF | |
| RATED POWER | 37.5W/75W/150W/OFF/16Ω |
| SENSITIVITY | 94dB 1watt/1 meter |
| MAXIMUM SPL | 116dB continuous,120dB peak |
| IMPEDANCE | 16 ohms nominal |
| DISPERSION(-6dB) | 90°×50° |
| CROSSOVER FREQUENCIES | 2.3kHz passive |
| INPUT CONNECTORS | Terminal clamp |
| PACKING SIZE | 370mm×310mm×525mm(carton/pc) |
| NET WEIGHT | 10kg/pc |
| GROSS WEIGHT | 12 kg/pair |
Product description
The supplier lists this product as PRO-Audio. The listed model is ES108/ES108T. The specifications below reflect the information publicly displayed on the listing. Model NO.: ES108/ES108T. Frequency Response(-3dB): 60Hz-18kHz. Driver: 1X1''(25mm)/1'' Voice Coil Hf. Rated Power: 37.5W/75W/150W/off/16Ω. Sensitivity: 94dB 1 Watt/1 Meter. Impedance: 16 Ohms Nominal.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 8′ ′ Waterproof Installation Speaker with 100V Transformer, IP46?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 8′ ′ Waterproof Installation Speaker with 100V Transformer, IP46 cost?
The published price is US$106.00 – 1,025.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
ES108/ES108T · US$106.00 – 1,025.00 · MOQ 1 Piece
