8X3″ Line Array Speaker
PA, Stage & Line-Array Speakers

8X3″ Line Array Speaker

Model: DLA803 Customization available Speakers & Audio Systems
US$334.00 – 2,670.00
MOQ 1 Piece
Rated Power
Lf:200W RMS, 800W Peak Hf:80W RMS, 320W Peak
Impedance
8 Ohms Nominal
Sensitivity
Lf:97dB 1watt/1meter; Hf:105dB 1watt/1meter
Application
Commercial
Requency Response(-3dB)
Lf:120Hz-18kHz; Hf:2kHz-18kHz
Drivers
8X3"(83mm)/0.8''voice Coil MID/High Unit
Send Inquiry Full specifications

Specifications

Product name8X3″ Line Array Speaker
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
ApplicationCommercial
Requency Response(-3dB)Lf:120Hz-18kHz; Hf:2kHz-18kHz
Model NO.DLA803
Drivers8X3"(83mm)/0.8''voice Coil MID/High Unit
Rated PowerLf:200W RMS, 800W Peak Hf:80W RMS, 320W Peak
SensitivityLf:97dB 1watt/1meter; Hf:105dB 1watt/1meter
Maximum Spl120dB Continuous, 126dB
Impedance8 Ohms Nominal
Dispersion(-6dB)Horizontal Coverage:90°
Crossover Frequencies1.5kHz Passive
Input Connectors2xspeakon Nl4
Specification780mm*500mm*470mm
OriginDongguan. China
HS Code8518220000
Production Capacity5000PCS/Month
DLA815BAS. Unit configuration8x3" neodymium mid-bass units, 4x1" exit
Applications1.Meeting rooms
Factory IntroductionFDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors.
Webfdbaudiochina.en.made-in-china.com
PriceUS$334.00-2,670.00 1 Piece(MOQ)
SupplierDONGGUAN FDB AUDIO MANUFACTURE CO .,LTD
Data retrieved2026-10-23

Available options

Rated Power
Lf:200W RMS800W Peak Hf:80W RMS320W Peak
Impedance8 Ohms Nominal
Input Connectors2xspeakon Nl4

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is DLA803. The specifications below reflect the information publicly displayed on the listing. Model NO.: DLA803. Drivers: 8X3"(83mm)/0.8''voice Coil MID/High Unit. Rated Power: Lf:200W RMS, 800W Peak Hf:80W RMS, 320W Peak. Sensitivity: Lf:97dB 1watt/1meter; Hf:105dB 1watt/1meter. Impedance: 8 Ohms Nominal. Input Connectors: 2xspeakon Nl4.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 8X3″ Line Array Speaker?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 8X3″ Line Array Speaker cost?

The published price is US$334.00 – 2,670.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
