Active Dual 10 Inch Line Array King910 professional Speaker DSP Audio Equipment
PA, Stage & Line-Array Speakers

Active Dual 10 Inch Line Array King910 professional Speaker DSP Audio Equipment

Model: KING910 Customization available Speakers & Audio Systems
US$672.002–19 Pieces
US$658.0020+ Pieces
MOQ 2 Pieces
Type
Class-D
Application
Commercial
Color
Black
Noise
<95dB
Hi-Fi
Hi-Fi
Activity
Active
Send Inquiry Full specifications

Specifications

Product nameActive Dual 10 Inch Line Array King910 professional Speaker DSP Audio Equipment
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
Noise<95dB
Hi-FiHi-Fi
Model NO.KING910
ActivityActive
Operation ModeAPP
Speaker SystemActive
Speaker MaterialWood
ApplicationCommercial
CertificationCE, RoHS
MonitorNo
THD<0.005%
Transport PackageCarton
Specification315 mm x 760 mm x 520 mm
OriginChina
ACOUSTICALFrequency Range
Horizontal100 degrees nominal (400 Hz-16 kHz)
VerticalVaries with array size and configuration
Maximum Peak Output138 dB SPL (Array preset, full-range)
System TypeLine Array, two-way powered
Low Frequency(2) R.C.F LF10N258 10 inch neodymium(V.C. 2.5")
High Frequency(1) J.B.L 2432H 1.5" exit neodymium compression driver with 3" V.C.
Input TypeBalanced line level
Connectors(2) XLR (IN/OUT)
Nominal Input Sensitivity+6 dBu (system starts limiting with broadband noise and music)
Maximum Input Level+21 dBu
Input Impedance100 kΩ
TypeClass-D
Number of Channels2 channels
Cooling TypeConvection, external aluminum heat sink, internal on-demand fan
Sample Rate48 kHz
Bit Depth24 bit
SpeedDual 100 Mbps ports
Enclosurebirch plywood cabinet, four handholds
ColorBlack
SuspensionThree-point, captive suspension plates, quick release pins, steel and aluminum
GrillePowder coated 1.5 mm (16 gauge) hex perforated steel with acoustically transparent dustproof fiber
Dimensions (H x W x D)315 mm x 760 mm x 520 mm
Net Weight30.35 kg
PriceUS$672.00 2-19 Pieces US$658.00 20+ Pieces
SupplierGuangzhou Skytone Audio Co., Limited
Data retrieved2026-10-23

Available options

Speaker MaterialWood
Connectors(2) XLR (IN/OUT)
Input Impedance100 kΩ
ColorBlack

Additional data

KING910Dual 10-inch Powered Line Array Loudspeaker
TECHNICAL SPECIFICATIONS
ACOUSTICAL:
Frequency Range
(-10 dB) :53 Hz-19 kHz (array preset)
(-3 dB) :60 Hz-18 kHz (array preset)
Coverage Pattern (-6 dB)
Horizontal:100 degrees nominal (400 Hz-16 kHz)
Vertical:Varies with array size and configuration
Maximum Peak Output:138 dB SPL (Array preset, full-range)
System Type :Line Array, two-way powered
TRANSDUCERS:
Low Frequency :(2) R.C.F LF10N258 10 inch neodymium(V.C. 2.5")
High Frequency :(1) J.B.L 2432H 1.5" exit neodymium compression driver with 3" V.C.
AUDIO INPUT
Input Type :Balanced line level
Connectors :(2) XLR (IN/OUT)
Nominal Input Sensitivity :+6 dBu (system starts limiting with broadband noise and music)
Maximum Input Level :+21 dBu
Input Impedance :100 kΩ
AMPLIFIER
Type :Class-D
Number of Channels :2 channels
RMS Power:1400 Watts( LF: 1000 Watts \| HF: 400 Watts )
Peak Power:2500 Watts(LF: 1800 Watts \| HF: 700 Watts )
Cooling Type :Convection, external aluminum heat sink, internal on-demand fan
DSP
Sample Rate :48 kHz
Bit Depth :24 bit
USER INTERFACE
Type :LCD, encoder, Back button, (7) LED Indicators (6 single, 1 bi-color)
NETWORKING
Type :RS485
Speed :Dual 100 Mbps ports
Connectors :(2) etherCON
AC POWER
Voltage Range90-130V / 180-250V VAC, 50/60 Hz
PHYSICAL
Enclosure :birch plywood cabinet, four handholds
Color :Black
Suspension :Three-point, captive suspension plates, quick release pins, steel and aluminum
Inter-enclosure Angle (deg)0.5, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12
Grille :Powder coated 1.5 mm (16 gauge) hex perforated steel with acoustically transparent dustproof fiber
Dimensions (H x W x D) :315 mm x 760 mm x 520 mm
Net Weight :30.35 kg

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is KING910. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: KING910. Speaker Material: Wood. Low Frequency : (2) R.C.F LF10N258 10 inch neodymium(V.C. 2.5"). High Frequency : (1) J.B.L 2432H 1.5" exit neodymium compression driver with 3" V.C.. Connectors : (2) XLR (IN/OUT). Nominal Input Sensitivity : +6 dBu (system starts limiting with broadband noise and music). Input Impedance : 100 kΩ.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Active Dual 10 Inch Line Array King910 professional Speaker DSP Audio?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Active Dual 10 Inch Line Array King910 professional Speaker DSP Audio cost?

The published price is US$658.00 – 672.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
