Active Mini Line Array Speaker with DSP Amplifier Module
PA, Stage & Line-Array Speakers

Active Mini Line Array Speaker with DSP Amplifier Module

Model: LA-2AN Customization available Speakers & Audio Systems
US$450.001–99 Pieces
US$400.00100+ Pieces
MOQ 1 Pieces
Power
Mf:350W/700W Hf:150W/300W
Impedance
Hf:4ohms Mf:8ohms
Application
Commercial
Color
Black
Operation Mode
Wire / Remote Control
Certification
CE, RoHS
Send Inquiry Full specifications

Specifications

Product nameActive Mini Line Array Speaker with DSP Amplifier Module
CategoryPA, Stage & Line-Array Speakers
Model NO.LA-2AN
Operation ModeWire / Remote Control
ApplicationCommercial
CertificationCE, RoHS
THD<0.005%
ColorBlack
PowerMf:350W/700W Hf:150W/300W
Active Line Array2-Way
Dispersion Angle(Vx H)75X 15°
Shipping Size562 * 309 *298 mm
ImpedanceHf:4ohms Mf:8ohms
Weight21kg
Warranty TimeOne Year
MOQ1PCS
Delivery TimeThree-Seven Days
Transport PackageCarton Box
OriginGuangdong China(Mainland)
Production Capacity100000
CustomizationAvailable
Noise<95dB
ActivityActive
LA2AN10",2-way line-array.Neo tweeter, 600+600W amplifier module,with built-in DSP
HF150W/300W MF:350W/700W
Trade termsMOQ
Our Service1. Provide professional person to communicate with you before the order.
Why us1. Selected Material,
PriceUS$450.00 1-99 Pieces US$400.00 100+ Pieces
SupplierGuangzhou MINGXUAN Stage Light Equipment CO.,LTD
Data retrieved2026-10-23

Available options

ColorBlack
PowerMf:350W/700W Hf:150W/300W
Shipping Size562 * 309 *298 mm
ImpedanceHf:4ohms Mf:8ohms

Additional data

Configuration10inch MF+2*1.75inch HF(neodynium)
Power(AES/Peak)HF:150W/300W MF:350W/700W
ImpedanceHF:4Ohms MF:8Ohms
Sensitivity (1 W/m)HF:135dB MF:128dB
Rated Maximum SPLHF:137dB peak,@1m MF:132dB peak,@1m
Dispersion angle(V × H)75°× 15°
ColorBlack
Weight21kg
Shipping Size562 * 309 *298 mm
MOQ1 square meter
Price termsEXW/FOB
PaymentT/T, Western Union, Paypal
OEM/ODMYES
Delivery time3-10 days after the payment
ShippingBy air, by sea, by DHL/Fedex/UPS/EMS
WarrantyOne Year

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is LA-2AN. The specifications below reflect the information publicly displayed on the listing. Model NO.: LA-2AN. Power: Mf:350W/700W Hf:150W/300W. Impedance: Hf:4ohms Mf:8ohms. Noise: <95dB.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Active Mini Line Array Speaker with DSP Amplifier Module?

The listed minimum order quantity is 1 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Active Mini Line Array Speaker with DSP Amplifier Module cost?

The published price is US$400.00 – 450.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
