Am1600 Single Channel Active Subwoofer Plate Amplifier Module
Subwoofers

Am1600 Single Channel Active Subwoofer Plate Amplifier Module

Model: AM1600 Customization available Speakers & Audio Systems
US$235.002–19 Pieces
US$230.0020+ Pieces
MOQ 2 Pieces
Type
Professional Amplifier
Usage
Active Audio Speaker System
Used For
Professional
Tube Type
Transistor Amplifier
Function
Amplifier Combined
Sound Channel
1
Send Inquiry Full specifications

Specifications

Product nameAm1600 Single Channel Active Subwoofer Plate Amplifier Module
CategorySubwoofers
CustomizationAvailable
TypeProfessional Amplifier
UsageActive Audio Speaker System
Model NO.AM1600
Used ForProfessional
Tube TypeTransistor Amplifier
FunctionAmplifier Combined
Sound Channel1
Output Number1
Voltage110V or 220V
Element NumberPush-Pull Amplifier
Conductive ModeD
8ω Bridged Power1×1600W
ProtectionShort Circuit DCP, Ovp, Uvp, Ocp, Otp
DSP FunctionMute, Polarity, Gain, Delay, Limiter, EQ, X-Over
DSP ControlUSB and RS-485
Net Weight3.6kg
Gross Weight5.5kg
Warranty2 Years
Transport PackageDurable Carton Box
Specification477x152x105mm
OriginChina
HS Code8518400000
Production Capacity2000 Pieces/Month
Package Size39.00cm * 35.00cm * 21.00cm
Package Gross Weight6.000kg
ClassD
The delivery timeit is 8-10 days if by air; it is 45-60 days if by sea.
PriceUS$235.00 2-19 Pieces US$230.00 20+ Pieces
SupplierAscsonic Audio Technology Co., Ltd
Data retrieved2026-10-23

Available options

Voltage110V or 220V
8ω Bridged Power1×1600W

Additional data

Model NameAM1600
8Ω Stereo Power1×1600W
Frequency Response20Hz-20KHz ±1dB
THD+N 1KHz 1W 8Ω<0.1%
Signal to Noise Ratio 1KHz>109dB
Channel Separation 1KHz>70dB
ClassClass: D
ProtectionShort Circuit DCP, OVP, UVP, OCP, OTP
Operating Voltage110V version: 90V-135V / 220V version: 180V-265V
Input Sensitivity1V
Input Impedance20KΩ
DSP FunctionMUTE, Polarity, Gain, Delay, Limiter, EQ, X-Over
DSP ControlUSB and RS-485
Dimensions(W×H×D) mm477*152*105
Net Weight(kg)3.6kg
Gross Weight(kg)5.5KG

Product description

The supplier lists this product as Professional Amplifier. Its stated application is Active Audio Speaker System. The listed model is AM1600. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: AM1600. 8ω Bridged Power: 1×1600W.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Am1600 Single Channel Active Subwoofer Plate Amplifier Module?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Am1600 Single Channel Active Subwoofer Plate Amplifier Module cost?

The published price is US$230.00 – 235.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
