Am3a 1500W+500W+500W 3CH Class D Plate Amplifier Module DSP
Speaker Amplifiers & Audio Processors

Am3a 1500W+500W+500W 3CH Class D Plate Amplifier Module DSP

Model: AM3A Customization available Cables, Adapters & Audio Electronics
US$430.002–19 Pieces
US$420.0020+ Pieces
MOQ 2 Pieces
Type
Professional Amplifier
Usage
Active PA Audio Speaker System
Used For
Professional
Tube Type
Transistor Amplifier
Function
Amplifier Combined
Sound Channel
3
Send Inquiry Full specifications

Specifications

Product nameAm3a 1500W+500W+500W 3CH Class D Plate Amplifier Module DSP
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
TypeProfessional Amplifier
UsageActive PA Audio Speaker System
Model NO.AM3A
Used ForProfessional
Tube TypeTransistor Amplifier
FunctionAmplifier Combined
Sound Channel3
Output Number3
Voltage110V or 220V
Element NumberPush-Pull Amplifier
Conductive ModeD
8ω Stereo Power(RMS)1500W+500W+500W
4ω Stereo Power(RMS)1800W+900W+900W
ProtectionShort Circuit DCP, Ovp, Uvp, Ocp, Otp
DSP FunctionMute, Polarity, Gain, Delay, Limiter, EQ, X-Over
DSP ControlUSB and RS-485
Net Weight5kg
Gross Weight6.5kg
Warranty2 Years
Transport PackageDurable Carton Box
Specification477*151.5*144mm
OriginChina
HS Code8518400000
Production Capacity2000 Pieces/Month
Package Size50.00cm * 18.00cm * 17.00cm
Package Gross Weight12.000kg
The delivery timeit is 8-10 days if by air; it is 45-60 days if by sea.
PriceUS$430.00 2-19 Pieces US$420.00 20+ Pieces
SupplierAscsonic Audio Technology Co., Ltd
Data retrieved2026-10-23

Available options

Voltage110V or 220V
8ω Stereo Power(RMS)1500W+500W+500W
4ω Stereo Power(RMS)1800W+900W+900W

Additional data

Ascsonic 3CH Class-D DSP Plate Amplifier Module with DSP+APF
SPECIFICATIONS
ITEM/MODELAM3AAM3A-2.1AM3A-2CHAM35A
8Ω Stereo PowerL:1500W+M:500W+H:500W1500W+2x500W2x1500WL:1500W+M:1500W+H:500W
4Ω Stereo PowerL:1800W+M:900W+H:900W1800W+2x900W2x1800WL:1800W+M:1800W+H:900W
Frequency Response20Hz-20KHz ±1dB
THD+N 1KHz 1W 8Ω<0.1%
Signal to Noise Ratio1KHz>100dB
Channel Separation1KHz>70dB
ClassD
ProtectionShort, DCP, OVP, UVP, OCP, OTP
Operating Voltage110V version: 90V-135V / 220V versioin: 180V-265V
Input Sensitivity1V
Input Impedance20KΩ
DSP FunctionMUTE, Polarity, Gain, Delay, Limiter, EQ, Xover, AFP
DSP ControlUSB and RS-485
Dimensions(W×H×D) mm477*151.5*144mm
Net Weight(kg)5kg8kg
Gross Weight(kg)6.5kg11kg

Product description

The supplier lists this product as Professional Amplifier. Its stated application is Active PA Audio Speaker System. The listed model is AM3A. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: AM3A. 8ω Stereo Power(RMS): 1500W+500W+500W. 4ω Stereo Power(RMS): 1800W+900W+900W.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Am3a 1500W+500W+500W 3CH Class D Plate Amplifier Module DSP?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Am3a 1500W+500W+500W 3CH Class D Plate Amplifier Module DSP cost?

The published price is US$420.00 – 430.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
