Ascsonic 900W Class D Am900 Stage Active Amplifier Module DSP Control
Speaker Amplifiers & Audio Processors

Ascsonic 900W Class D Am900 Stage Active Amplifier Module DSP Control

Model: AM900 Customization available Cables, Adapters & Audio Electronics
US$235.002–19 Pieces
US$230.0020+ Pieces
MOQ 2 Pieces
Type
Professional Amplifier
Usage
Active Audio Speaker System
Used For
Professional
Tube Type
Transistor Amplifier
Function
Amplifier Combined
Sound Channel
1
Send Inquiry Full specifications

Specifications

Product nameAscsonic 900W Class D Am900 Stage Active Amplifier Module DSP Control
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
TypeProfessional Amplifier
UsageActive Audio Speaker System
Model NO.AM900
Used ForProfessional
Tube TypeTransistor Amplifier
FunctionAmplifier Combined
Sound Channel1
Output Number1
Voltage110V or 220V
Element NumberPush-Pull Amplifier
Conductive ModeD
8ω Bridged Power1×900W
ProtectionShort Circuit DCP, Ovp, Uvp, Ocp, Otp
DSP FunctionMute, Polarity, Gain, Delay, Limiter, EQ, X-Over
DSP ControlUSB and RS-485
Net Weight3.6kg
Gross Weight5.5kg
Warranty2 Years
Transport PackageDurable Carton Box
Specification477x152x105mm
OriginChina
HS Code8518400000
Production Capacity2000 Pieces/Month
Package Size39.00cm * 35.00cm * 21.00cm
Package Gross Weight6.000kg
ClassD
Available modelsAM5002 2-Channel Plate Amplifier
ApplicationsPowered Speaker \| Active Loudspeaker \| Subwoofer System \| Stage Monitor \| Professional PA System \| Audio Installation
The delivery timeit is 8-10 days if by air; it is 45-60 days if by sea.
PriceUS$235.00 2-19 Pieces US$230.00 20+ Pieces
SupplierAscsonic Audio Technology Co., Ltd
Data retrieved2026-10-23

Available options

Voltage110V or 220V
8ω Bridged Power1×900W
Available modelsAM5002 2-Channel Plate Amplifier

Additional data

AM5002AM1600AM900
8Ω Stereo Power2×500W
4Ω Stereo Power2×900W
8Ω Bridged Power1*1600w ONLY1*900W
4Ω Bridged Power1*1800w
Frequency Response20Hz-20KHz ±1dB
THD+N 1KHz 1W 8Ω<0.1%
Signal to Noise Ratio1KHz>100dB
Channel Separation1KHz>70dBN/AN/A
ClassClass: D
ProtectionShort,DCP,OVP,UVP,OCP,OTP
Operating Voltage110V version: 90V-135V / 220V version: 180V-265V
Input Sensitivity1V
Input Impedance20KΩ
DSP FunctionMUTE, Polarity, Gain, Delay, Limiter, EQ, X-Over
DSP ControlUSB and RS-485
Dimensions(W×H×D) mm477*151.5*89mm
Packing Dimension (mm)
Net Weight(kg)3.36KG
Gross Weight(kg)5.5KG

Product description

The supplier lists this product as Professional Amplifier. Its stated application is Active Audio Speaker System. The listed model is AM900. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: AM900. 8ω Bridged Power: 1×900W. Available models: AM5002 2-Channel Plate Amplifier.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Ascsonic 900W Class D Am900 Stage Active Amplifier Module DSP Control?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Ascsonic 900W Class D Am900 Stage Active Amplifier Module DSP Control cost?

The published price is US$230.00 – 235.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
