Audio Line Array Woofer 65mm Vc 10″ Neodymium Speaker
Speaker Drivers, Woofers & Tweeters

Audio Line Array Woofer 65mm Vc 10″ Neodymium Speaker

Model: EL10NC65 Customization available Speaker Parts & Accessories
US$56.901–49 Pieces
US$51.9050–499 Pieces
US$46.90500+ Pieces
MOQ 1 Pieces
Power
200W
Application
Commercial
Noise
<95dB
Activity
Passive
Operation Mode
Wire / Remote Control
Speaker System
Optional Combination
Send Inquiry Full specifications

Specifications

Product nameAudio Line Array Woofer 65mm Vc 10″ Neodymium Speaker
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
Noise<95dB
Model NO.EL10NC65
ActivityPassive
Operation ModeWire / Remote Control
Speaker SystemOptional Combination
Speaker MaterialMetal
ApplicationCommercial
CertificationCE, RoHS
THD<0.03%
Power200W
N.W.2.8 Kg
G.W.3.3 Kg
Nominal Diameter254mm/10 Inch
Nominal Impedance8 Ohm
Sensitivity 1W/1m95dB
Frequency Range73-7.8kHz
Transport PackageCarton
Specification260*127
OriginChina
HS Code85182900
Production Capacity100000 PCS/Year
PriceUS$56.90 1-49 Pieces US$51.90 50-499 Pieces US$46.90 500+ Pieces
SupplierMeirui (Guangdong) Audio Equipment Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialMetal
Power200W
Nominal Diameter254mm/10 Inch
Nominal Impedance8 Ohm

Additional data

General Specifications
Nominal Diameter254mm/10 inch
Nominal Impedance8Ω
AES Power Handing200W
Maximum Power300W
Sensitivity 1W/1M95dB
Frequency Range73-7.8KHz
Voice Coil Diameter65.5mm/2.6 inch
Windinig MaterialEICCAW
Former MaterialKapton
Winding Depth16.5mm
surround materialPolycotton
surround DesignM-roll
MagnetNeodymium Ring
Thiele & Small Parameters
Resonance FrequencyFs73HZ
DC ResistanceRe5.7Ω
Mechanical FactorQms8.59
Electrical FactorQes0.46
Total FactorQts0.44
BL FactorBL16T.m
Effective Moving MassMms43g
ComplianceCms111μ M/N
Equivalent Cas Air LoadVas19L
Effettive Piston AreaSd346cm2
η(Eta Zero)η01.52%
Mountiong & Shipping Information
Overall Diameter260mm
Bolt circle diameter244mm
Baffle Cutout Diameter230mm
Depth127mm
Net Weight2.8kg
Shipping Weight3.3kg
Shipping Box(Single)26.5*26.5*14.5cm

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is EL10NC65. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: EL10NC65. Speaker Material: Metal. Power: 200W. Nominal Impedance: 8 Ohm. Sensitivity 1W/1m: 95dB. Frequency Range: 73-7.8kHz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Audio Line Array Woofer 65mm Vc 10″ Neodymium Speaker?

The listed minimum order quantity is 1 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Audio Line Array Woofer 65mm Vc 10″ Neodymium Speaker cost?

The published price is US$46.90 – 56.90 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
