China Active Speaker Line Array Powered Line Array Speaker Cabinet
PA, Stage & Line-Array Speakers

China Active Speaker Line Array Powered Line Array Speaker Cabinet

Model: CVR. W-102P Customization available Speakers & Audio Systems
Price on request
MOQ 1 Piece
Power
350watt RMS Each Cabinet
Type
Two Way Full Range Line Array Speaker System
Application
Commercial
Speaker Material
Wood
Certification
CE, RoHS
Size
10"X1 Lf, 2.5"X1hf
Send Inquiry Full specifications

Specifications

Product nameChina Active Speaker Line Array Powered Line Array Speaker Cabinet
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
Speaker MaterialWood
ApplicationCommercial
Model NO.CVR. W-102P
CertificationCE, RoHS
TypeTwo Way Full Range Line Array Speaker System
Size10"X1 Lf, 2.5"X1hf
Power350watt RMS Each Cabinet
CabinetBirch Plywood Cabinet
PaintingWaterproof Textured Painting
BrandCvr PRO Audio
DriversNeodynium Components
Transport PackageCarton
SpecificationHIGH QUALITY
OriginGuagnzhou, China
HS Code851822
Production Capacity5000PCS/Month
WAHT WE CAN OFFER YOUIf you are searching a reliable pro sound equipment supplier, CVR PRO-AUDIO is your best choice.
A wide range of applications, includingHouses of worship
PriceNegotiable 1 Piece(MOQ)
SupplierCVR PRO AUDIO CO.,LTD
Data retrieved2026-10-23

Available options

Speaker MaterialWood
Size
10"X1 Lf2.5"X1hf
Power350watt RMS Each Cabinet

Additional data

ModelW-110 & W-118/W-110P & W-118P(Active)
TypeLine array system
line array sub-bass system(W-118/W-118P)
Frequency Response65Hz-20KHz±3dB
35Hz-500Hz±3dB(W-118/W-118P)
Power handlingLF 350W(RMS)700W(PEAK)
HF 90W(RMS)180W(PEAK)
600W(RMS)1200W(PEAK)
Power amp600W/8ohm (W-110P) / 900W/8ohm (W-118P)
Amplifier typeSwitching power amp, class D circuit
Other functionsbuilt-in crossover(W-110P)
SensitivityLF 96dB(1W@1M)
HF 108dB(1W@1M)
109dB(1W@1M)(W-118/W-118P)
Max@S.P.LLF 122dB(PEAK/1M)
HF 125dB(PEAK/1M)
135dB(PEAK/1M)(W-118/W-118P)
LF section1×10"(260mm) neodymium woofer
75mm(3in)coil
1×18"(460mm)woofer
100mm(4in)coil (W-118/W-118P)
Nominal impedance16 ohm
8 ohm (W-118/W-118P)
HF section1x2.5"compression driver with44mm
titanium diaphragm
Output section2-channel
Dispersion pattern110º H×9º V
Surface finishBlack paint
Array designArrays of less than 3×W-110 will
provide poor dispersion control and are
neither recommended nor supported
Speaker cablesLF1(+)1(-) HF 2(+)2(-)
1(+)1(-) (W-118/W-118P)
Rigging systemPlease refer to the W-110 user's
manual before any operation
Input connectors2×NL4MP speakon
Recommend crossoverLF 70Hz-2KHz
HF 2KHz-20KHz
35Hz-120Hz(W-118/W-118P)
Dimensions546×291×410mm(W×H×D)
546×510×650mm(W×H×D)(W-118/ W-118P)
Package dimensions610×360×480mm/0.11cbm
610×575×715mm/0.25cbm (W-118/ W-118P)
EnclosureBirch Plywood
Net weight21kg(W-110)/40kg(W-118)/46kg(W-118P)
Gross weight23kg(W-110)/43kg(W-118)/49kg(W-118P)

Product description

The supplier lists this product as Two Way Full Range Line Array Speaker System. Its stated application is Commercial. The listed model is CVR. W-102P. The specifications below reflect the information publicly displayed on the listing. Speaker Material: Wood. Model NO.: CVR. W-102P. Power: 350watt RMS Each Cabinet. Drivers: Neodynium Components.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for China Active Speaker Line Array Powered Line Array Speaker Cabinet?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does China Active Speaker Line Array Powered Line Array Speaker Cabinet cost?

The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
