Compression Driver Unit Speaker Horn Tweeter (TW-344)
- Material
- Aluminum
- Type
- Speaker
- Speaker Design
- Tweeter
- Shape
- Basin-shaped
- Sound Frequency
- High Pitch
- Voltage
- 24V
Specifications
| Product name | Compression Driver Unit Speaker Horn Tweeter (TW-344) |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Type | Speaker |
| Speaker Design | Tweeter |
| Model NO. | TW-344 |
| Shape | Basin-shaped |
| Material | Aluminum |
| Sound Frequency | High Pitch |
| Voltage | 24V |
| Connection Mode | Double Wire |
| Contact Point | Without Contact Point |
| Energy Exchanging Mechanism | Electrical |
| Nominal Impedance | 8 Ohm |
| Diaphragm Material | Pi Polymer Composite |
| Voice Coil Diameter | 1.35" (34.4mm) |
| Voice Coil Material | Copper Clad Aluminum Round Wire |
| Transport Package | Strengthen The Carton Packaging +Color Box Packing |
| Specification | CE |
| Origin | Ningbo |
| HS Code | 851829000 |
| Production Capacity | 1000PCS/Week |
| Specifications | Model No. |
| Mounting Type | Bolt-on |
| Power Capacity | 80Watts RMS (pink noise signal -12db/OCT) |
| Sensitivity(1W/1M) | 108dB |
| Frequency Range | 500Hz-18KHz |
| Flux Density | 1.8T |
| Magnet | Strontium Ferrite |
| Pcs/CTN | 16PCS |
| Price | US$6.50 500 Pieces(MOQ) |
| Supplier | Ningbo Yinzhou Join Industry Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Material | Aluminum |
|---|---|
| Voltage | 24V |
| Diaphragm Material | Pi Polymer Composite |
| Voice Coil Diameter | 1.35" (34.4mm) |
| Voice Coil Material | Copper Clad Aluminum Round Wire |
| Nominal Impedance | 8 Ohm |
Additional data
| Model No. | TW 344 |
|---|---|
| Mounting Type: | Bolt-on |
| Nominal Impedance: | 8 Ohm |
| Power Capacity: | 80Watts RMS (pink noise signal -12db/OCT) |
| Sensitivity(1W/1M): | 108dB |
| Frequency Range: | 500Hz-18KHz |
| Diaphragm Material: | Composite Polyester/Titanium |
| Voice Coil Diameter | 1.35" (34.4mm) |
| Voice Coil Material | Pure Aluminum Ribbon Wire |
| Flux Density: | 1.8T |
| Magnet: | Strontium Ferrite |
| Pcs/CTN: | 16PCS |
Product description
The supplier lists this product as Speaker. The listed model is TW-344. The specifications below reflect the information publicly displayed on the listing. Model NO.: TW-344. Material: Aluminum. Sound Frequency: High Pitch. Nominal Impedance: 8 Ohm. Diaphragm Material: Pi Polymer Composite. Voice Coil Material: Copper Clad Aluminum Round Wire. Power Capacity: 80Watts RMS (pink noise signal -12db/OCT). Sensitivity(1W/1M): 108dB. Frequency Range: 500Hz-18KHz.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Compression Driver Unit Speaker Horn Tweeter (TW-344)?
The listed minimum order quantity is 500 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Compression Driver Unit Speaker Horn Tweeter (TW-344) cost?
The published price is US$6.50 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
TW-344 · US$6.50 · MOQ 500 Pieces
