D2l&D2s 2 Channels Active Module, Amplifier Module for Speaker
- Frequency Response
- 20Hz-20kHz ±1db
- Type
- 2CH Amplifier Module
- Application
- Commercial, Home
- Noise
- <95dB
- Hi-Fi
- Not Hi-Fi
- Activity
- Active
Specifications
| Product name | D2l&D2s 2 Channels Active Module, Amplifier Module for Speaker |
|---|---|
| Category | Other Speakers & Sound Systems |
| Customization | Available |
| Noise | <95dB |
| Hi-Fi | Not Hi-Fi |
| Model NO. | D2L& D2S |
| Activity | Active |
| Operation Mode | Wire / Remote Control |
| Speaker System | Optional Combination |
| Speaker Material | Metal |
| Application | Commercial, Home |
| Certification | CE, RoHS |
| Monitor | VFD Screen |
| THD | <0.005% |
| Type | 2CH Amplifier Module |
| Class | D |
| Frequency Response | 20Hz-20kHz ±1db |
| Transport Package | Double Corrugated Carton |
| Specification | CE |
| Origin | Made in China |
| HS Code | 8518220000 |
| Production Capacity | 800PCS/Month |
| D2L | 312*190*88 / D2S: 312*140*125 |
| Company Home Page | https://cnsanway.en.made-in-china.com/ |
| Facebook Home Page | https://cnsanway.en.made-in-china.com/ |
| Price | US$100.00-400.00 1 Piece(MOQ) |
| Supplier | Sanway Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Metal |
|---|
Additional data
| ITEM/MODLE | D2L / D2S | D2L-SUB8 / D2S-SUB8 | D2L-SUB4 / D2S-SUB4 | D2L-TWO / D2S-TWO |
|---|---|---|---|---|
| Output Power | ||||
| 8Ω Stereo Power | 2×500W | 2×500W | ||
| 4Ω Stereo Power | 2×900W | 2×900W | ||
| 8Ω Bridged Power | 1*1600w ONLY | 1*900W | ||
| 4Ω Bridged Power | 1*1800w |
| Frequency Response | 20Hz-20KHz ±1dB |
|---|---|
| THD+N 1KHz 1W 8Ω | <0.1% |
| Signal to Noise Ratio 1KHz | >109dB |
| Channel Separation 1KHz | >70dB |
| Class | Class: D |
| Protection | Short,DCP,OVP,UVP,OCP,OTP |
| Operating Voltage | 115V version: 90V-135V / 230V version: 180V-265V |
| Input Sensitivity | 0.77V |
| Input Impedance | 20KΩ |
| DSP Fuction | MUTE,Polarity,Gain,Delay, Limiter,Mixer,EQ,X-Over |
| DSP Control | USB and RS-485 |
| Dimensions(W×H×D) mm | D2L: 312*190*88 / D2S: 312*140*125 |
| Packing Dimension (mm) | D2L: 350*210*120 / D2S: 350*170*160 |
| Net Weight(kg) | D2L: 3.8 / D2S: 3.6 |
| Gross Weight(kg) | D2L: 4.8 / D2S: 4.6 |
Product description
The supplier lists this product as 2CH Amplifier Module. Its stated application is Commercial, Home. The listed model is D2L& D2S. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: D2L& D2S. Speaker Material: Metal. Frequency Response: 20Hz-20kHz ±1db.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for D2l&D2s 2 Channels Active Module, Amplifier Module for Speaker?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does D2l&D2s 2 Channels Active Module, Amplifier Module for Speaker cost?
The published price is US$100.00 – 400.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
D2L& D2S · US$100.00 – 400.00 · MOQ 1 Piece
