dB-Net Series Digital DSP Audio Matrix Matrix Switcher Audio Conference System
Speaker Amplifiers & Audio Processors

dB-Net Series Digital DSP Audio Matrix Matrix Switcher Audio Conference System

Model: VIS-DSP4/DSP8/DSP12/DSP16 Customization available Cables, Adapters & Audio Electronics
US$10.00 – 99,999.00
MOQ 1 Piece
Communication
Wired
Type
Audio Matrix
Color
Black
Video
Without Video
Composition
Regulator
Pointing Feature
Omni-Directional
Send Inquiry Full specifications

Specifications

Product namedB-Net Series Digital DSP Audio Matrix Matrix Switcher Audio Conference System
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
ColorBlack
TypeAudio Matrix
Model NO.VIS-DSP4/DSP8/DSP12/DSP16
VideoWithout Video
CompositionRegulator
CommunicationWired
Pointing FeatureOmni-Directional
Transport PackageCarton
OriginChina
HS Code85176239
Production Capacity10000
Each channel has independent mute/Invert/Phontom control,sensitive0dBu to -60dBu
Threshold-56dBFS to 0dBFS, Ratio:1 to 20, Attack:1ms to 1000ms, Release:1ms to 1000ms
bandwidth0.02oct to 4.00oct, step-over: 0.01oct, gain: -15db to + 15db, step-over: 0.01db.
Gain-72dB to 12dB, Slop:1 to 3, Response:5ms to 5000ms
Filter typesLinkwitz-Riley/Bessel/Butterworth, frequency: 20Hz to 20 KHz, resolution with 1Hz attenuation slope: 12db / oct. 18db/oct24db/oct30db/oct 6db/oct42db/oct48db/oct.
Each output channel includes a separate 31-band equalizer;OctavesNarrow/Normal/Wide
PriceUS$10.00-99,999.00 1 Piece(MOQ)
SupplierVISSONIC Electronics Ltd.
Data retrieved2026-10-23

Available options

ColorBlack

Additional data

ModelDSP4DSP8DSP12DSP16
Input channel jacksMulti-channel terminal-block jacks (1 x 4 total inputs)Multi-channel terminal-block jacks (2 x 4 total inputs)Multi-channel terminal-block jacks (3 x 4 total inputs)Multi-channel terminal-block jacks (4 x 4 total inputs)
Output channel jacksMulti-channel terminal-block jacks (1x 4 total outputs)Multi-channel terminal-block jacks (2 x 4 total outputs)Multi-channel terminal-block jacks (3 x 4 total outputs)Multi-channel terminal-block jacks (4 x 4 total outputs)
General Purpose Input Output8 Freely configurable input and output
Input impedance20kΩ balance,10kΩ unbalance
Output impedance100Ω balance,50Ω unbalance
PC port≥RS485 interface (RJ-45), network-port, RS232.
Input CMRR≥80 dB @ +24dBu @60Hz
Input range≤+24dBu.
Frequency response20~20kHz (±0.25dB)
S/N R>90dB@0dBu,1KHz
THD+N≤0.002% @1kHz,+4dBu
Crosstalk of channels>100dB(1KHz).
Functions of input channels
mute/Invert/Phontom/sensitiveEach channel has independent mute/Invert/Phontom control,sensitive:0dBu to -60dBu
Test ToneSine wave/Pink/White
ExpanderThreshold:-56dBFS to 0dBFS, Ratio:1 to 20, Attack:1ms to 1000ms, Release:1ms to 1000ms
EQEach input channel includes a separate 5-band parametric equalizer; center frequency from 20Hz to 20KHz bandwidth: 0.02oct to 4.00oct, step-over: 0.01oct, gain: -15db to + 15db, step-over: 0.01db.
CompressThreshold:-48dBFS to 0dBFS, Ratio:1 to 20, Attack:1ms to 1000ms, Release:1ms to 1000ms
AGCThreshold:-60dBFS to 0dBFS, Targer:Threshold to 0dBFS, Ratio:1 to 20, Attack:1ms to 1000ms, Release:1ms to 1000ms
Auto MixerGain:-72dB to 12dB, Slop:1 to 3, Response:5ms to 5000ms
AFC/AECAutomatic Feedback Cancel/Automatic Echo Cancel
MixerIt is called also matrix or routing.
Functions of output channels
Output delayEach output channel has delay (0ms to 2000ms or delay Distance from 0m to 640m)
X-overEach output channel can be set independently with a low-pass (LPF) and high pass (HPF) filter (all with adjustable parameters). Filter types: Linkwitz-Riley/Bessel/Butterworth, frequency: 20Hz to 20 KHz, resolution with 1Hz attenuation slope: 12db / oct. 18db/oct24db/oct30db/oct 6db/oct42db/oct48db/oct.
Output GEQEach output channel includes a separate 31-band equalizer;Octaves:Narrow/Normal/Wide
LimitThreshold:-56dBFS to 0dBFS, Release:1ms to 1000ms
mute/InvertEach output channel has independent mute/Invert control.
cameraIt can connect and control the camera
Processor48KHz sampling frequency, 24 bits of data
Power consumption≤40W≤45W
PowerAC 90V/240V 50Hz/60Hz.
Product dimension(W×D×H)482X260X44mm.
Net weight2.2(kg).
Shipping dimension(W×D×H)1 piece: 550x400x140mm/0.0244m3
Gross weight1 piece: 3.3(kg)

Product description

The supplier lists this product as Audio Matrix. The listed model is VIS-DSP4/DSP8/DSP12/DSP16. The specifications below reflect the information publicly displayed on the listing. Model NO.: VIS-DSP4/DSP8/DSP12/DSP16.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for dB-Net Series Digital DSP Audio Matrix Matrix Switcher Audio?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does dB-Net Series Digital DSP Audio Matrix Matrix Switcher Audio cost?

The published price is US$10.00 – 99,999.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
