Digital Professional Amplifier Module Board Class D Power AMP for Full-Range Speakers
- Output Power
- 8ohms 300W
- Type
- Professional Amplifier
- Usage
- Hi-Fi, AV
- Used For
- Professional
- Tube Type
- Transistor Amplifier
- Function
- Post Amplifier
Specifications
| Product name | Digital Professional Amplifier Module Board Class D Power AMP for Full-Range Speakers |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Type | Professional Amplifier |
| Usage | Hi-Fi, AV |
| Model NO. | GX-609(DSP) |
| Used For | Professional |
| Tube Type | Transistor Amplifier |
| Function | Post Amplifier |
| Sound Channel | 2.1 |
| Output Number | 4 |
| Voltage | AC 220V |
| Element Number | Push-Pull Amplifier |
| Conductive Mode | D |
| Output Circuit | Class H |
| S/N Ratio | 105dB |
| Input Sensitivity | 0.775V/1.0V/1.44V |
| Limiting Protection | Can Reach 4V |
| Output Power | 8ohms 300W |
| Thd at 1kHz and 1dB Below Clipping | 0.5% |
| Hum and Noise | 90dB |
| Slew Rate | 35V/Us |
| Damping Factor | 200 |
| Input Connectors | XLR Combo |
| Link Connectors | XLR Male |
| Limit and Clip Indicator | Red LED |
| Power on Indicator | Green LED |
| Sensitivity Switch | 0.7V |
| Treble /Bass EQ | Yes |
| Transport Package | Carton |
| Specification | 483*450*88mm |
| Origin | Guangzhou |
| HS Code | 8518400090 |
| Price | Negotiable 10 Pieces(MOQ) |
| Supplier | Guangzhou Seer Audio Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | AC 220V |
|---|---|
| Output Power | 8ohms 300W |
| Power on Indicator | Green LED |
| Input Connectors | XLR Combo |
| Link Connectors | XLR Male |
Additional data
| Model | GX-609(DSP) |
|---|---|
| Output Power | 8ohms 600W |
| THD at 1KHz and 1dB below clipping | 0.70% |
| Hum and Noise | 92dB |
| Slew Rate | 35V/us |
| Damping Factor | 200 |
| Input connectors | XLR Combo |
| Link connectors | XLR male |
| Limit and Clip indicator | Red LED |
| Power ON indicator | Green LED |
| Sensitivity Switch | 0.7V |
| Treble /Bass EQ | Yes |
| Mic/ line Switch | Yes |
| OUtput connectors | Cable |
| Operation voltage, 230V/115V | 198-242V |
| Soft start | Yes |
| Minimum start-up voltage, 230V | 198V |
| Dimensions | 320*150*89mm |
| N.W. | 2.5kg |
Product description
The supplier lists this product as Professional Amplifier. Its stated application is Hi-Fi, AV. The listed model is GX-609(DSP). Supplier-stated function: Post Amplifier. The specifications below reflect the information publicly displayed on the listing. Model NO.: GX-609(DSP). Input Sensitivity: 0.775V/1.0V/1.44V. Output Power: 8ohms 300W. Hum and Noise: 90dB. Input Connectors: XLR Combo. Link Connectors: XLR Male. Power on Indicator: Green LED. Sensitivity Switch: 0.7V.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Digital Professional Amplifier Module Board Class D Power AMP for?
The listed minimum order quantity is 10 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Digital Professional Amplifier Module Board Class D Power AMP for cost?
The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
