DMX Cable/AES-Ebu Cable/DMX-512 Cable/Digital Cable/Microphone Cable/Instrument Cable/Speaker Cable/Cat Network Cable/Coaxial Cable
- Application
- Construction, Industrial, Power Station, Telecommunication, Car
- Voltage
- Low and Medium Voltage Cable
- Current
- AC Cable
- Insulation Material
- XLPE/PVC/PE/Lsoh
- Sheath Material
- PVC/PE/Lsoh
- Material Shape
- Round Wire
Specifications
| Product name | DMX Cable/AES-Ebu Cable/DMX-512 Cable/Digital Cable/Microphone Cable/Instrument Cable/Speaker Cable/Cat Network Cable/Coaxial Cable |
|---|---|
| Category | Speaker Wire & Speaker Cables |
| Application | Construction, Industrial, Power Station, Telecommunication, Car |
| Voltage | Low and Medium Voltage Cable |
| Current | AC Cable |
| Model NO. | Control Cable&Instrument Cable |
| Insulation Material | XLPE/PVC/PE/Lsoh |
| Sheath Material | PVC/PE/Lsoh |
| Material Shape | Round Wire |
| Wire Core Material | Bare Copper Wire |
| Certification | ISO, CCC, CE, RoHS, VDE |
| Model | KVVP |
| Brand | Cynid |
| Shielding | Tinned Copper Wire Braiding |
| Insulated Color | Red, Blue,Yellow, Black. White and So on |
| Transport Package | Drum |
| Specification | 1.5mm2 to 16mm2 |
| Origin | China |
| HS Code | 8544492100 |
| Production Capacity | 1000km/Year |
| Package Size | 210.00cm * 100.00cm * 100.00cm |
| Package Gross Weight | 100.000kg |
| Lead Time | 12 days (1 - 10000 Meters) To be negotiated ( > 10000 Meters) |
| Price | US$0.50 1,000 Meters(MOQ) |
| Supplier | Cynid Electric Power Co.,Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | Low and Medium Voltage Cable |
|---|---|
| Insulation Material | XLPE/PVC/PE/Lsoh |
| Sheath Material | PVC/PE/Lsoh |
| Material Shape | Round Wire |
| Wire Core Material | Bare Copper Wire |
| Insulated Color |
Additional data
| Technical characteristics of control cable | |||||
|---|---|---|---|---|---|
| No. of core×Nominal cross section | Nominal thicknessof insulation | Nominal thicknessof sheath | Approx.overall diameter | Approx.weight of cable | Max. DC. resistance of conductor(20℃) |
| mm2 | mm | mm | mm | kg/km | Ω/km |
| 4×1.5 | 0.6 | 1.5 | 14.4 | 355 | 12.1 |
| 5×1.5 | 0.6 | 1.5 | 15.2 | 395 | 12.1 |
| 6×1.5 | 0.6 | 1.5 | 17.0 | 545 | 12.1 |
| 7×1.5 | 0.6 | 1.5 | 17.2 | 564 | 12.1 |
| 8×1.5 | 0.6 | 1.5 | 18.2 | 625 | 12.1 |
| 10×1.5 | 0.6 | 1.5 | 19.8 | 720 | 12.1 |
| 12×1.5 | 0.6 | 1.5 | 20.2 | 775 | 12.1 |
| 14×1.5 | 0.6 | 1.7 | 21.3 | 845 | 12.1 |
| 16×1.5 | 0.6 | 1.7 | 22.2 | 925 | 12.1 |
| 19×1.5 | 0.6 | 1.7 | 23.7 | 1130 | 12.1 |
| 24×1.5 | 0.6 | 1.7 | 26.5 | 1340 | 12.1 |
| 27×1.5 | 0.6 | 1.7 | 26.9 | 1420 | 12.1 |
| 30×1.5 | 0.6 | 1.7 | 27.7 | 1495 | 12.1 |
| 37×1.5 | 0.6 | 1.7 | 29.3 | 1690 | 12.1 |
| 44×1.5 | 0.6 | 2.0 | 33.2 | 2041 | 12.1 |
| 48×1.5 | 0.6 | 2.0 | 33.8 | 2118 | 12.1 |
| 52×1.5 | 0.6 | 2.0 | 34.5 | 2233 | 12.1 |
| 61×1.5 | 0.6 | 2.0 | 37.5 | 2728 | 12.1 |
| 4×2.5 | 0.7 | 1.5 | 17.0 | 560 | 7.41 |
| 5×2.5 | 0.7 | 1.5 | 18.0 | 625 | 7.41 |
| 6×2.5 | 0.7 | 1.5 | 19.0 | 705 | 7.41 |
| 7×2.5 | 0.7 | 1.5 | 19.2 | 715 | 7.41 |
| 8×2.5 | 0.7 | 1.5 | 20.6 | 815 | 7.41 |
| 10×2.5 | 0.7 | 1.7 | 23.7 | 1090 | 7.41 |
| 12×2.5 | 0.7 | 1.7 | 24.2 | 1170 | 7.41 |
| 14×2.5 | 0.7 | 1.7 | 25.1 | 1245 | 7.41 |
| 16×2.5 | 0.7 | 1.7 | 26.2 | 1350 | 7.41 |
| 19×2.5 | 0.7 | 1.7 | 27.3 | 1500 | 7.41 |
| 24×2.5 | 0.7 | 1.7 | 30.6 | 1790 | 7.41 |
| 27×2.5 | 0.7 | 2.0 | 32.3 | 1990 | 7.41 |
| 30×2.5 | 0.7 | 2.0 | 33.2 | 2110 | 7.41 |
| 37×2.5 | 0.7 | 2.0 | 35.9 | 2640 | 7.41 |
| 44×2.5 | 0.7 | 2.2 | 39.9 | 3060 | 7.41 |
| 48×2.5 | 0.7 | 2.2 | 40.3 | 3210 | 7.41 |
| 52×2.5 | 0.7 | 2.2 | 41.4 | 3360 | 7.41 |
| 61×2.5 | 0.7 | 2.2 | 43.5 | 3730 | 7.41 |
Product description
The supplier lists this product. Its stated application is Construction, Industrial, Power Station, Telecommunication, Car. The listed model is Control Cable&Instrument Cable. The specifications below reflect the information publicly displayed on the listing. Model NO.: Control Cable&Instrument Cable. Insulation Material: XLPE/PVC/PE/Lsoh. Sheath Material: PVC/PE/Lsoh. Material Shape: Round Wire. Wire Core Material: Bare Copper Wire. Model: KVVP.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for DMX Cable/AES-Ebu Cable/DMX-512 Cable/Digital Cable/Microphone?
The listed minimum order quantity is 1,000 meters. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does DMX Cable/AES-Ebu Cable/DMX-512 Cable/Digital Cable/Microphone cost?
The published price is US$0.50 per meter. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Customization depends on the manufacturer and order quantity. Describe what you need and we will confirm the options.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
