Double 10′ ′ Compact Line Array Loudspeaker (very high SPL)
PA, Stage & Line-Array Speakers

Double 10′ ′ Compact Line Array Loudspeaker (very high SPL)

Model: NX510&NX510A Customization available Speakers & Audio Systems
US$1.00 – 3,000.00
MOQ 1 Piece
Frequency Response(-3dB) Hf
1kHz-18kHz
Woofer
2X10"(250mm)/3" Voice Coil Woofer
Driver
3X1"(25mm)/1.7" Voice Coil Tweeter
Rated Power(Lf)
600W RMS, 2400W Peak
Rated Power(Hf)
180W RMS, 720W Peak
Sensitivity(Lf)
106dB 1 Watt/1 Meter
Send Inquiry Full specifications

Specifications

Product nameDouble 10′ ′ Compact Line Array Loudspeaker (very high SPL)
CategoryPA, Stage & Line-Array Speakers
Model NO.NX510&NX510A
Frequency Response(-3dB) Hf1kHz-18kHz
Woofer2X10"(250mm)/3" Voice Coil Woofer
Driver3X1"(25mm)/1.7" Voice Coil Tweeter
Rated Power(Lf)600W RMS, 2400W Peak
Rated Power(Hf)180W RMS, 720W Peak
Sensitivity(Lf)106dB 1 Watt/1 Meter
Sensitivity(Hf)111dB 1 Watt/1 Meter
Maximum Spl(Lf)134dB Continuous, 140dB Peak
Maximum Spl(Hf)134dB Continuous, 140dB Peak
Dispersion(-6dB)90°×30°
Crossover Frequencies1.5kHz Passive
Specification650x520x695mm(NX510);
OriginDongguan, China
HS Code8518220000
Production Capacity5000PCS/Month
CustomizationAvailable
CertificationCE, RoHS
Frequency Response(-3dB) Lf70Hz-2.5kHz
Factory IntroductionFDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors.
Webfdbaudiochina.en.made-in-china.com
LF70Hz-2.5kHz HF:1kHz-18kHz
PriceUS$1.00-3,000.00 1 Piece (MOQ)
SupplierDONGGUAN FDB AUDIO MANUFACTURE CO .,LTD
Data retrieved2026-10-23

Available options

Rated Power(Lf)
600W RMS2400W Peak
Rated Power(Hf)
180W RMS720W Peak

Additional data

FREQUENCY RESPONSE(-3dB)LF:70Hz-2.5kHz HF:1kHz-18kHz
DRIVERS2×10"(250mm)/3"voice coil LF
3×1"(36mm)/1.7"voice coil HF
RATED POWER600W RMS,2400W peak
SENSITIVITY106dB 1watt/1 meter
MAXIMUM SPL134dB continuous,140dB peak
IMPEDANCE8 ohms nominal
DISPERSION(-6dB)90°×30°
CROSSOVER FREQUENCIES1.5kHz passive
INPUT CONNECTORS2×Speakon NL4
PACKING SIZE650mm×520mm×695mm
NET WEIGHT35kg/pc
GROSS WEIGHT39 kg/pc

Product description

The supplier lists this product. The listed model is NX510&NX510A. The specifications below reflect the information publicly displayed on the listing. Model NO.: NX510&NX510A. Frequency Response(-3dB) Hf: 1kHz-18kHz. Driver: 3X1"(25mm)/1.7" Voice Coil Tweeter. Rated Power(Lf): 600W RMS, 2400W Peak. Rated Power(Hf): 180W RMS, 720W Peak. Sensitivity(Lf): 106dB 1 Watt/1 Meter. Sensitivity(Hf): 111dB 1 Watt/1 Meter. Frequency Response(-3dB) Lf: 70Hz-2.5kHz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Double 10′ ′ Compact Line Array Loudspeaker (very high SPL)?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Double 10′ ′ Compact Line Array Loudspeaker (very high SPL) cost?

The published price is US$1.00 – 3,000.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
