Double 10 Inch Line Array Speaker Professional Compact Loudspeaker Line Array System
PA, Stage & Line-Array Speakers

Double 10 Inch Line Array Speaker Professional Compact Loudspeaker Line Array System

Model: BRX310LA Customization available Speakers & Audio Systems
US$9,300.00
MOQ 1 Set
Impedance
8 Ohms
Frequency response
50Hz -18KHz
Application
Commercial, Live Performance
Noise
≥105dB
Hi-Fi
Professional Line Array
Activity
Active
Send Inquiry Full specifications

Specifications

Product nameDouble 10 Inch Line Array Speaker Professional Compact Loudspeaker Line Array System
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
Noise≥105dB
Hi-FiProfessional Line Array
Model NO.BRX310LA
ActivityActive
Operation ModeWire / Remote Control
Speaker SystemProfessional Line Array
Speaker MaterialWood
ApplicationCommercial, Live Performance
CertificationCE
MonitorNon
THD<0.005%
ConfigurationDual 10" Line Array
Impedance8 Ohms
Handle Power1100W/2200W
Spl136dB
Hf1 X 3" Compression Driver
Lf2 X 10" Driver
Components MaterialNeodymium
Connections2 X Nl4 Speakon
CabinetBirch Plywood
FinishPolyurea Paint
Transport PackageCarton Case or Flight Case
Specification2x10"
OriginChina
HS Code8518220000
Production Capacity300PCS/Month
Package Size54.00cm * 44.00cm * 83.00cm
Package Gross Weight30.000kg
BRX310LA line array8PCS
BRX310LA flight case4PCS
STX828S subwoofer4PCS
STX828S flight case4PCS
BRX310 flying bar2PCS
SRX812P stage monitor2PCS
SRX812P flight case1PCS
Amplifier for BRX310LA2PCS
Amplifier for STX828S2PCS
DSP0408 processor1PCS
DF10P power sequencer1PCS
Grace 12 mixer1PCS
ATX400+/H microphone1PCS
Rack case1PCS
ModelBRX310LA
Features1. Light weight
System TypeSelf powered 12", two-way, bass-refex
Frequency Range (-10 dB)40 Hz - 21 kHz
Frequency Response (±3 dB)48 Hz - 20 kHz
Coverage Pattern90° x 50° nominal (Monitor position)
Crossover Frequency1.9 kHz
LF Driver1 x (12 inch) FERRITE woofer
HF Driver1 x (1.7 inch) FERRITE tweeter
Enclosure18 mm, 13-ply birch plywood.
Suspension / Mounting36 mm pole socket
Handles3
GrillePowder coated, black, 14-gauge perforated steel with
Input ConnectorsXLR input, XLR output
Dimensions (H x W x D)572 mm x 364 mm x 380 mm
Gross weight21kg
T12044X1200W/8ohms
T15044X1500W/8ohms
T20044X2000W/8ohms
T25044X2500W/8ohms
T28044X2800W/8ohms
Frequency range555-580 MHz
Receiving sensitivity-94dBm for 30dB
Mirror suppression>60dB
Frequency stability± 0.005%
Modulation methodFM
Maximum frequency offset± 45KHz
Audio response50Hz -18KHz (± 3dB)
Signal to noise ratio>105dB
System distortion<0.5%
Working temperature-10 ° C~55 ° C
Power supply12-18V DC 600mA
Harmonic radiation<-63dBm
Band width40MHz
Maximum input sound pressure130dB SPL
Current consumption<110 mA
Transmission power30mW
Frequency response50Hz -18KHz
PriceUS$9,300.00 1 Set(MOQ)
SupplierGuangzhou Skytone Audio Co., Limited
Data retrieved2026-10-23

Available options

Speaker MaterialWood
Handle Power1100W/2200W
Components MaterialNeodymium
Impedance8 Ohms
DF10P power sequencer1PCS
Input Connectors
XLR inputXLR output

Additional data

Model:BRX310LA
SYSTEM TYPEModular, portable line array
Frequency Range(-10 dB)50 Hz - 20 kHz
Coverage110° x 12° (variable)
LF Driver2 x 10" woofer
HF Driver1 x3" tweeter
System Power RatingHF:1x100WLF:2x500W
Maximum SPL(1m)136 dB
Nominal Impedance8Ω
FinishBlack Polyurea Paint
MaterilalPlywood
Input ConnectorNL4 Speakon
Dimensions(HxWxD)325 mm x 755 mm x 410 mm
Net Weight27.8 kg
ModelSTX828S
System type2 way 2X18" subwoofer
Frequency Range ( -10 dB)32 Hz-250 Hz
Frequency Response (± 3 dB)37 Hz-120 Hz
Sensitivity (1W/1m)99 dB
Power Rating2000 W / 4000 W / 8000 W
(Continuous/Program/Peak)
Rated Maximum SPL138 dB SPL Peak
Nominal Impedance4Ω
Input ConnectorsTwo NL4
Operational ModesSubwoofer
Paint564 mm x 1137 mm x 714 mm
CabinetImported polyurea paint
Recommend amplifier18mm birch plywood
WarrantyI--tech 18000 (2X1800Watts) Digital amplifier
Dimensions (H x W x D)564 mm x 1137 mm x 714 mm
Net Weight82KG
SRX812P Stage Monitor Speaker Specifications
System Type:Self powered 12", two-way, bass-refex
Maximum SPL output136 dB
Frequency Range (-10 dB):40 Hz - 21 kHz
Frequency Response (±3 dB):48 Hz - 20 kHz
Coverage Pattern:90° x 50° nominal (Monitor position)
Crossover Frequency:1.9 kHz
LF Driver:1 x (12 inch) FERRITE woofer
HF Driver:1 x (1.7 inch) FERRITE tweeter
Power1200W peak, 600W continuous
Enclosure:18 mm, 13-ply birch plywood.
Suspension / Mounting:36 mm pole socket 12 x M10 Suspension points
Handles:3
Finish:Black finish
Grille:Powder coated, black, 14-gauge perforated steel with acoustical transparent charcoal foam backing.
Input Connectors:XLR input, XLR output Powercon
Dimensions (H x W x D):572 mm x 364 mm x 380 mm
Gross weight:21kg
Technical parametersT1204T1504T2004T2504T2804
Rated power(RMS )( 20Hz-20KHZ≤0.1%THD )8 Q-stereo1200W*41500Wx42000Wx42500Wx42800Wx4
4 Q-stereo2400W*43000Wx44000Wx45000Wx45600Wx4
2 Q-stereo4800Wx46000Wx48000Wx410000Wx411200Wx4
Limiting protectionCan reach 10VCan reach 10VCan reach 10VCan reach 10VCan reach 10V
Frequency response( 1W 8ohms)20HZ-20KHZ(±0.1db)
Sensitivity( 8ohms 1KHz)0.775v/26/32db
Total harmonic distortion<0.02%@8Ω1KHZ<0.03%@8Ω1KHZ<0.03%@8Ω1KHZ<0.08%@8Ω1KHZ<0.08%@8Ω1KHZ
Phase response≤±1.5°≤±2°≤±3°≤±3°≤±3°
Conversion rate≥50V/μs≥50V/μs≥50V/μs≥50V/μs≥50V/μs
Crosstalk attenuation≥75db≥65db≥60db≥60db≥60db
Signal-to-noise ratio≥108db≥107db≥105db≥105db≥105db
Damping coefficient≥800≥800≥800≥900≥900
Intermodulation distortion≤0.02%≤0.02%≤0.02%≤0.02%≤0.02%
Output circuit typeCLASS-D
Installation space2U
Chassis size (WxHxD)482×88×475mm
Gross weight2123262832
Technical support and after-sales serviceInternationalized technical team support; Global 1-year warranty (non human damage)
ModelDSP 0408F
Input / Output4-in 8-out
Input impendance10K Ohm
Output impendance50 Ohm
Max. input / output level19 dBu
Gain-40dB ~ +12dB, steps 1dB / 0.1dB
DelayON/OFF, 0ms ~ 1000ms,
steps 105/10.5/1.05/0.105/0.021 (ms)
PEQ bands1 ~ 15
PEQ BypassON/OFF
PEQ TypePEQ, Low-shelf 6dB, Low-shelf 12dB,
High-shelf 6dB, High-shelf 12dB,
Phase-shifter
PEQ Frequency19.7Hz ~ 21.9kHz
PEQ Gain-30dB ~ +15dB , steps 1dB / 0.1dB
Compressor's KneeOff/Hard Knee/ Soft knee1/
Soft knee2/ Soft knee3/
Soft knee4/ Soft knee5
Compressor's Threshold-20 dB ~ +20 dB, steps 0.5dB
Compressor's Ratio1.2, 1.5, 2, 3, 4, 6, 10, 20, 40, 128
Compressor's Attack-Time0 ms ~ 1000 ms , steps 1ms
Compressor's Release-Time50 ms ~ 1000 ms , steps 50ms
High/Low-Pass19.7Hz ~ 21.9kHz
Filter Frequency19.7Hz ~ 21.9kHz
High/Low-Pass Filter SolpeFlat THRU, 12dB, 24dB, 36dB, 48dB
High/Low-Pass Filter TypesBessel,Butterworth,Linkwitz-Riley,
Dynamic range116dB A Weighting
Separation degree< -100dB
Distortion0.003% (1kHz, 0 dBu)
System preset10 entry presets, 30 user programs
Power SupplyAC 90V - 250V, 50HZ -60Hz
Weight2.5kg
Dimension482mm x 158mm x 45mm
Receiver(Host):
Frequency range: 555-580 MHz
610-690 Mhz
803-806 Mhz
905-930 Mhz
Receiving sensitivity: -94dBm for 30dB
Mirror suppression:>60dB
Frequency stability: ± 0.005%
Modulation method: FM
Maximum frequency offset: ± 45KHz
Audio response: 50Hz -18KHz (± 3dB)
Signal to noise ratio:>105dB
Dynamic range>100dB
System distortion:<0.5%
Working temperature: -10 ° C~55 ° C
Power supply: 12-18V DC 600mA
Handheld Transmitter(MicroPhone):
Harmonic radiation:<-63dBm
Band width: 40MHz
Maximum input sound pressure: 130dB SPL
Current consumption:<110 mA
Transmission power: 30mW
Frequency response: 50Hz -18KHz
Power supply: 2x1.5V AA battery

Product description

The supplier lists this product. Its stated application is Commercial, Live Performance. The listed model is BRX310LA. The specifications below reflect the information publicly displayed on the listing. Noise: ≥105dB. Model NO.: BRX310LA. Speaker Material: Wood. Impedance: 8 Ohms. Handle Power: 1100W/2200W. Components Material: Neodymium. DF10P power sequencer: 1PCS. Model: BRX310LA. Frequency Range (-10 dB): 40 Hz - 21 kHz. Frequency Response (±3 dB): 48 Hz - 20 kHz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Double 10 Inch Line Array Speaker Professional Compact Loudspeaker?

The listed minimum order quantity is 1 set. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Double 10 Inch Line Array Speaker Professional Compact Loudspeaker cost?

The published price is US$9,300.00 per set. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
