Double 12″ 3-Way Professional Line Array Speaker
- Impedance
- 8 Ohms Nominal
- Sensitivity
- 103dB 1 Watt/1 Meter
- Application
- Live Show
- Noise
- <102dB
- Hi-Fi
- Not Hi-Fi
- Activity
- Passive
Specifications
| Product name | Double 12″ 3-Way Professional Line Array Speaker |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Noise | <102dB |
| Hi-Fi | Not Hi-Fi |
| Model NO. | MLA8312&MLA8312DA |
| Activity | Passive |
| Application | Live Show |
| Certification | CE, RoHS |
| Frequency Response(-3dB) (Lf) | 50Hz-3kHz |
| Frequency Response(-3dB)(Mf+Hf) | 400Hz-18kHz |
| Woofer | 2X12"(300mm)/3" Voice Coil Woofer |
| Mediant | 4X6"(160mm)/2" Vc Neodymium Mediant |
| Driver | 2X1.4"(36mm)/3" Vc Neodymium Tweeter |
| Rated Power(Lf) | 800W RMS, 3200W Peak |
| Rated Power(Mf+Hf) | 400W RMS, 1600W Peak |
| Impedance | 8 Ohms Nominal |
| Sensitivity | 103dB 1 Watt/1 Meter |
| Maximum Spl | 129dB Continuous, 135dB Peak |
| Dispersion(-6dB) | Horizontal Coverage 100° |
| Crossover Frequencies | 400Hz, 1.3kHz Passive |
| Transport Package | Carton Box |
| Specification | 570x480x1240mm |
| Origin | Dongguan, China |
| HS Code | 8518220000 |
| Production Capacity | 3000PCS/Month |
| Applications | 1.Multi-purpose Halls |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Direct | 0086-(0)769-89820683 |
| Fax | 0086-(0)769-22781297 |
| Web | fdbaudiochina.en.made-in-china.com |
| Horizontal coverage | 100° |
| Price | US$1.00-3,000.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Rated Power(Lf) | |
|---|---|
| Rated Power(Mf+Hf) | |
| Impedance | 8 Ohms Nominal |
Additional data
| MODEL | MLA8312 ( Full range speaker) |
|---|---|
| FREQUENCY RESPONSE(-3dB) | 50Hz-18kHz |
| DRIVERS | 2×12"(300mm)/3"voice coil LF |
| 4×6"(160mm)/2" voice coil MF | |
| 2×1.4"(36mm)/3"voice coil HF | |
| RATED POWER | 400W RMS,1600W peak |
| SENSITIVITY | 103dB 1watt/1 meter |
| MAXIMUM SPL | 129 dB continuous,135 dB peak |
| IMPEDANCE | 8 ohms nominal |
| DISPERSION(-6dB) | Horizontal coverage:100° |
| Varies, depending on array length and configuration | |
| CROSSOVER FREQUENCIES | 400Hz, 1.3kHz passive |
| INPUT CONNECTORS | 2×Speakon NL4 |
| NET WEIGHT | 50 kg/pc |
| GROSS WEIGHT | 56 kg/pc(Carton/pc) |
Product description
The supplier lists this product. Its stated application is Live Show. The listed model is MLA8312&MLA8312DA. The specifications below reflect the information publicly displayed on the listing. Noise: <102dB. Model NO.: MLA8312&MLA8312DA. Frequency Response(-3dB) (Lf): 50Hz-3kHz. Frequency Response(-3dB)(Mf+Hf): 400Hz-18kHz. Driver: 2X1.4"(36mm)/3" Vc Neodymium Tweeter. Rated Power(Lf): 800W RMS, 3200W Peak. Rated Power(Mf+Hf): 400W RMS, 1600W Peak. Impedance: 8 Ohms Nominal. Sensitivity: 103dB 1 Watt/1 Meter.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Double 12″ 3-Way Professional Line Array Speaker?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Double 12″ 3-Way Professional Line Array Speaker cost?
The published price is US$1.00 – 3,000.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
