Double 12′ ′ Passive/Active 2.5-Way Line Array Loudspeaker with Neodymium Components
PA, Stage & Line-Array Speakers

Double 12′ ′ Passive/Active 2.5-Way Line Array Loudspeaker with Neodymium Components

Model: MLA212/MLA212DA Customization available Speakers & Audio Systems
US$1.00 – 3,000.00
MOQ 1 Piece
Rated Power
800W RMS, 3200W Peak
Impedance
8 Ohms Nominal
Sensitivity
101dB 1 Watt/1 Meter
Application
Commercial
Certification
CE, RoHS
Monitor
No Screen
Send Inquiry Full specifications

Specifications

Product nameDouble 12′ ′ Passive/Active 2.5-Way Line Array Loudspeaker with Neodymium Components
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
ApplicationCommercial
CertificationCE, RoHS
Model NO.MLA212/MLA212DA
MonitorNo Screen
Frequency Response(-3dB)50Hz-18kHz
Woofer2X12"(300mm)/3" Voice Coil Woofer
Driver2X1.4"(36mm)/3" Voice Coil Tweeter
Rated Power800W RMS, 3200W Peak
Sensitivity101dB 1 Watt/1 Meter
Impedance8 Ohms Nominal
Maximum Spl130dB Continuous, 136dB Peak
Dispersion(-6dB)Horizontal:100
Crossover Frequencies400Hz, 1.3kHz Passive
Transport PackageCarton Box/Flight Case
Specification570x480x1055mm(MLA212);
OriginDongguan, China
HS Code8518220000
Production Capacity5000PCS/Month
Factory IntroductionFDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors.
Webfdbaudiochina.en.made-in-china.com
Horizontal100°
PriceUS$1.00-3,000.00 1 Piece(MOQ)
SupplierDONGGUAN FDB AUDIO MANUFACTURE CO .,LTD
Data retrieved2026-10-23

Available options

Rated Power
800W RMS3200W Peak
Impedance8 Ohms Nominal

Additional data

FREQUENCY RESPONSE(-3dB)50Hz-18kHz
DRIVERS2×12"(300mm)/3"voice coil LF
2×1.4"(36mm)/3"voice coil HF
RATED POWER800W RMS,2000W peak
SENSITIVITY101dB 1watt/1 meter
MAXIMUM SPL130dB continuous,136dB peak
IMPEDANCE8 ohms nominal
DISPERSION(-6dB)Horizontal: 100°
CROSSOVER FREQUENCIES400Hz, 1.3kHz passive
INPUT CONNECTORS2×Speakon NL4
PACKING SIZE570mm×480mm×1055mm
NET WEIGHT41 kg/pc
GROSS WEIGHT47 kg/pc

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is MLA212/MLA212DA. The specifications below reflect the information publicly displayed on the listing. Model NO.: MLA212/MLA212DA. Frequency Response(-3dB): 50Hz-18kHz. Driver: 2X1.4"(36mm)/3" Voice Coil Tweeter. Rated Power: 800W RMS, 3200W Peak. Sensitivity: 101dB 1 Watt/1 Meter. Impedance: 8 Ohms Nominal.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Double 12′ ′ Passive/Active 2.5-Way Line Array Loudspeaker with?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Double 12′ ′ Passive/Active 2.5-Way Line Array Loudspeaker with cost?

The published price is US$1.00 – 3,000.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
