Dragonstage Hts12 12 Channel Professional Audio Mixer with DSP Effects
Speaker Amplifiers & Audio Processors

Dragonstage Hts12 12 Channel Professional Audio Mixer with DSP Effects

Model: HTS12 12 Channel Professional Audio Mixer Customization available Cables, Adapters & Audio Electronics
US$228.00
MOQ 1 Piece
Frequency Response
20Hz-20kHz (+3db)
Application
Concert
THD
0.05%
Mono Microphone Inputs
12 Channels
Stereo Inputs
2 Channels
Noise
>93db
Send Inquiry Full specifications

Specifications

Product nameDragonstage Hts12 12 Channel Professional Audio Mixer with DSP Effects
CategorySpeaker Amplifiers & Audio Processors
Model NO.HTS12 12 Channel Professional Audio Mixer
THD0.05%
Mono Microphone Inputs12 Channels
Stereo Inputs2 Channels
Frequency Response20Hz-20kHz (+3db)
Transport PackagePaper Box
Specification575 × 475 × 125mm
OriginGuangzhou, China
CustomizationAvailable
Noise>93db
ApplicationConcert
The HTS12 provides12 mono microphone input channels
The integrated DSP system provides24 selectable digital effects
Each input channel featuresFour-band equalization
The HTS12 supportsLeft and right main outputs
The HTS12 includesBluetooth audio playback
The mixer supports48V phantom power
The HTS12 is suitable forSmall and medium concerts
The HTS12 Professional Audio Mixer is ideal forStage performances
The HTS12 can be integrated withPower Amplifiers
PriceUS$228.00 1 Piece (MOQ)
SupplierFOSHAN DRAGON STAGE EQUIPMENT CO.,LTD
Data retrieved2026-10-23

Additional data

SpecificationHTS12
Product TypeProfessional Audio Mixer
Mono Microphone Inputs12 Channels
Stereo Inputs2 Channels
Channel EQ4-Band EQ with Mid Sweep
DSP Effects24 Built-in Effects
Main OutputsLeft / Right Stereo Output
AUX Outputs3 AUX Outputs
Group Outputs4 Group Outputs
Phantom Power48V Independent Channel Control
Master EQDual 7-Band Equalizer
MP3 PlayerBluetooth + Recording Function
MP3 Display2.5-inch Dot Matrix Screen
USB Sound CardBuilt-in
Signal-to-Noise Ratio>93dB
THD0.05%
Frequency Response20Hz-20kHz (+3dB)
AUX Send Output Level0dBu
Maximum Output Level17dBu (1kΩ, THD=0.5%)
Headphone Output Maximum Level17dBu / 150Ω (+25dBm)
Power Supply100-240V, 6A, 250V
Product Dimensions575 × 475 × 125mm
Packing Dimensions635 × 185 × 570mm
Net Weight7.25kg

Product description

The supplier lists this product. Its stated application is Concert. The listed model is HTS12 12 Channel Professional Audio Mixer. The specifications below reflect the information publicly displayed on the listing. Model NO.: HTS12 12 Channel Professional Audio Mixer. Frequency Response: 20Hz-20kHz (+3db). Noise: >93db.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Dragonstage Hts12 12 Channel Professional Audio Mixer with DSP Effects?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Dragonstage Hts12 12 Channel Professional Audio Mixer with DSP Effects cost?

The published price is US$228.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
