Dual 10 Inch PRO Audio Line Array Cabinet
- Power
- (RMS)Lf600W, Hf160W/ 1200W
- Frequency Response
- 60Hz-20kHz/40Hz-150Hz
- Sensitivity
- Lf99db, Hf108db/112db
- Material
- Neodymium
- Type
- Line Array System
- Application
- Commercial
Specifications
| Product name | Dual 10 Inch PRO Audio Line Array Cabinet |
|---|---|
| Category | Grilles, Cabinets & Enclosures |
| Model NO. | W-210A & W-250A |
| Certification | CE, RoHS, CCC, FCC, ETL, MET |
| Type | Line Array System |
| Size | 2X10" Lf, 2X2 Hf(W-210A)/ 2X15"(W-250A) |
| Frequency Response | 60Hz-20kHz/40Hz-150Hz |
| Sensitivity | Lf99db, Hf108db/112db |
| Power | (RMS)Lf600W, Hf160W/ 1200W |
| Material | Neodymium |
| Finish | Water-Proof, Birch Plywood |
| Net Weight | 42kg/72kg |
| Dimension | 855X293X600mm/855X440X820mm |
| Warranty | Two Years Free Warranty |
| Transport Package | Quality Carton Box or Flight Case |
| Specification | CE, RoHS |
| Origin | China |
| HS Code | 851822 |
| Production Capacity | 10000 PCS/Month |
| Customization | Available |
| Speaker Material | Wood |
| Application | Commercial |
| Price | US$200.00-2,000.00 1 Piece (MOQ) |
| Supplier | CVR PRO AUDIO CO.,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Size | |
|---|---|
| Power | |
| Material | Neodymium |
| Speaker Material | Wood |
Additional data
| Model | W-210A/W-250A |
|---|---|
| Type | Line array system |
| Line array sub-bass system(W-250A) | |
| Frequency Response | 55Hz-20KHz±3dB |
| 40Hz-150Hz±3dB(W-250A) | |
| Directivity index(Dl) | 12(±2)1.2KHz-16KHz |
| Power handing | LF 500W(RMS)1000W(PEAK) |
| HF 160W(RMS)320W(PEAK) | |
| 1200W(RMS)2400W(PEAK)(W-250A) | |
| Sensitivity | LF 99dB(1Wat1M) |
| HF 108dB(1Wat 1M) | |
| 112dB(1W at 1M)(W-250A) | |
| Max S.P.L | LF 127dB(PEAK/1M) |
| HF 127dB(PEAK/1M) | |
| 143dB(PEAK/1M)(W-250A) | |
| LF section | 2×10"(260mm) neodymium woofer |
| 75mm(3in)coil | |
| Components | 2×15"(380mm) neodymium woofers |
| 100mm(4in)coil(W-250A) | |
| Nominal impedance | 16 ohm |
| 4 ohm(W-250A) | |
| HF section | 2×2"neodymium compression driver |
| with 51mm titanium diaphragm | |
| Output section | 2-channel |
| Dispersion pattern | 110°H×9°V |
| Finish | Water-proof,wear-resistant textured black paint |
| Array design | Arrays of less than 3×W-210A will |
| provide poor dispersion control and | |
| are neither recommended nor supported | |
| Speaker cables | LF 1(+)1(-) HF 2(+)2(-) |
| 1(+)1(-) (W-250A) | |
| Rigging system | Please refer to the W-210A user |
| manual before any operation | |
| Input connectors | 2×NL4MP speakon |
| Recommend crossover | LF 45Hz-1200Hz |
| HF 1200Hz-20KHz | |
| 35Hz-120Hz(W-250A) | |
| Dimensions | 855×293×600mm(W×H×D) |
| 855×610×820mm(W×H×D)(W-250A) | |
| Package dimensions | 925×360×670mm/0.22cbm |
| 925×680×890mm/0.56cbm(W-250A) | |
| Enclosure | Birch plywood |
| Net weight | 42kg (W-210A)/ 81kg (W-250A) |
| Gross weight | 45kg (W-210A)/ 84kg (W-250A) |
Product description
The supplier lists this product as Line Array System. Its stated application is Commercial. The listed model is W-210A & W-250A. The specifications below reflect the information publicly displayed on the listing. Model NO.: W-210A & W-250A. Frequency Response: 60Hz-20kHz/40Hz-150Hz. Sensitivity: Lf99db, Hf108db/112db. Power: (RMS)Lf600W, Hf160W/ 1200W. Material: Neodymium. Speaker Material: Wood.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Dual 10 Inch PRO Audio Line Array Cabinet?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Dual 10 Inch PRO Audio Line Array Cabinet cost?
The published price is US$200.00 – 2,000.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
