Excellent Performance Pilot Aviation Headset with 6.3mm Connectors in Ga Plug
Call Center, Business & Aviation Headsets

Excellent Performance Pilot Aviation Headset with 6.3mm Connectors in Ga Plug

Model: PH-100A Customization available Headphones & Earphones
US$50.00 – 85.00
MOQ 50 Pieces
Impedance
150 ohms (300 ohms each; wired in parallel)
Frequency Response
100Hz to 8 kHz
Sensitivity
95+/-5 dB SPL
Jack Type
6.3mm
Wire Material
PU
Style
Headband
Send Inquiry Full specifications

Specifications

Product nameExcellent Performance Pilot Aviation Headset with 6.3mm Connectors in Ga Plug
CategoryCall Center, Business & Aviation Headsets
CustomizationAvailable
Wire MaterialPU
ColorMulti-Color
Model NO.PH-100A
TypeDynamic Headphones
UsageAviation
FunctionNoise-Canceling
Jack Type6.3mm
Ran-1000A ColorRed/Blue/Pink/Gray/Green/Black/Yellow/Gray
Ran-1000A ConnectorTwo-Plug
Ran-1000A ApplicationAirplane/Airline/Pilot/Aircraft
Warranty12months
Ran-1000A Microphoneflexible Boom Microphone
EarFoam Ear Seal/Gel Ear Seal/
Ran-1000A PlugGa Use Dual Plug
Noise CancelingPassive Nrr:24 dB Rating
Brand NameRaytalk or OEM
OEM ProduceAvailable
StyleHeadband
Microphonewith Microphone
Earpad SizeOne Size
Transport PackageStandard Airworthy Packing
SpecificationCE/ISO
OriginShenzhen of China
HS Code85183010
Production Capacity1000PCS/Week
Noise Reduction Ratings (NRR)24dB
Frequency Response100Hz to 8 kHz
Sensitivity95+/-5 dB SPL
Impedance150 ohms (300 ohms each; wired in parallel)
Rate Input100mW
Max. Input250mW
Element TypeNoise-canceling electret
Operating Voltage (supplied by aircraft )8-32 Volts DC
Matching Impedance150-1000 ohms
Operating Temperature-20 to 70 °C
CordageStraight cord from headset to molded
Earphone PlugPJ-055( .25"F6.3 phone plug)
Microphone PlugPJ-068( .206"F5.2 phone plug)
Weights530g
Headset size range Height10 to 14 cm
BoomSpring tension booM
Packagesheadset in a paper box.
MOQ24/pcs
PriceUS$50.00-85.00 50 Pieces(MOQ)
SupplierRAYTALK COMMUNICATIONS LTD
Data retrieved2026-10-23

Available options

Wire MaterialPU
ColorMulti-Color
Ran-1000A ColorRed/Blue/Pink/Gray/Green/Black/Yellow/Gray
Earpad SizeOne Size
Ran-1000A ConnectorTwo-Plug
Impedance
150 ohms (300 ohms eachwired in parallel)

Product description

The supplier lists this product as Dynamic Headphones. Its stated application is Aviation. The listed model is PH-100A. Supplier-stated function: Noise-Canceling. The specifications below reflect the information publicly displayed on the listing. Wire Material: PU. Model NO.: PH-100A. Ran-1000A Connector: Two-Plug. Noise Canceling: Passive Nrr:24 dB Rating. Noise Reduction Ratings (NRR): 24dB. Frequency Response: 100Hz to 8 kHz. Sensitivity: 95+/-5 dB SPL. Impedance: 150 ohms (300 ohms each; wired in parallel). Matching Impedance: 150-1000 ohms.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Excellent Performance Pilot Aviation Headset with 6.3mm Connectors in?

The listed minimum order quantity is 50 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Excellent Performance Pilot Aviation Headset with 6.3mm Connectors in cost?

The published price is US$50.00 – 85.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
