Factory 2268HPL Neodymium Speaker Driver, 18 Inch Subwoofer Speaker Driver
Speaker Drivers, Woofers & Tweeters

Factory 2268HPL Neodymium Speaker Driver, 18 Inch Subwoofer Speaker Driver

Model: 2268HPL Customization available Speaker Parts & Accessories
US$99.00
MOQ 2 Pieces
Impedance
8 Ohms
Sensitivity
96 dB 1W/1m
Application
Commercial
Noise
<95dB
Hi-Fi
Speaker Driver
Activity
Speaker Driver
Send Inquiry Full specifications

Specifications

Product nameFactory 2268HPL Neodymium Speaker Driver, 18 Inch Subwoofer Speaker Driver
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
Noise<95dB
Hi-FiSpeaker Driver
Model NO.2268HPL
ActivitySpeaker Driver
Operation ModeSpeaker Driver
Speaker SystemSpeaker Driver
Speaker MaterialSpeaker Driver
ApplicationCommercial
CertificationCE, RoHS
MonitorNon
THD<0.005%
Power Handling (RMS)800 Watts
Power Handling (Max)1, 600 Watts
Impedance8 Ohms
Sensitivity96 dB 1W/1m
Voice Coil Diameter3"
Cone MaterialPaper
Magnet MaterialNeodymium
Overall Outside Diameter18.125"
Baffle Cutout Diameter16.625"
Depth8.875"
Transport Package50*50*25cm/PCS 6.6kg/PCS
Specification1PCS/CTN
OriginGuangzhou, China
HS Code8518290000
Production Capacity200PCS/Month
Package Size46.00cm * 45.00cm * 45.00cm
Package Gross Weight11.000kg
We can offer you1. Competitive advantage products
Overview of 2268HPL 18'' Lf High Quality Neodymium WooferThe 2268HPL Differential Drive 18" speaker is the driver of choice for premium, high quality professional subwoofer systems.
Highlights of 2268HPL 18'' Lf High Quality Neodymium WooferTour-class woofer with patented motor design
Suitable for the following model professional speaker1. SRX718S subwoofer
Good feedbacks from clientsOther models HF and LF are available
LF262H-- 12" neodymium woofer speaker
PriceUS$99.00 2 Pieces(MOQ)
SupplierGuangzhou Skytone Audio Co., Limited
Data retrieved2026-10-23

Available options

Speaker MaterialSpeaker Driver
Power Handling (RMS)800 Watts
Power Handling (Max)
1600 Watts
Voice Coil Diameter3"
Cone MaterialPaper
Magnet MaterialNeodymium

Additional data

2268HPL PRODUCT SPECIFICATIONS
Power Handling (RMS)800 Watts
Power Handling (max)1,600 Watts
Impedance8 ohms
Sensitivity96 dB 1W/1m
Voice Coil Diameter3"
THIELE-SMALL PARAMETERS
Resonant Frequency (Fs)33 Hz
DC Resistance (Re)5.3 ohms
Voice Coil Inductance (Le)1.85 mH
Mechanical Q (Qms)3.80
Electromagnetic Q (Qes)0.39
Total Q (Qts)0.36
Compliance Equivalent Volume (Vas)11.58 ft.³
Maximum Linear Excursion (Xmax)8 mm
MATERIALS OF CONSTRUCTION
Cone MaterialPaper
Magnet MaterialNeodymium
MOUNTING INFORMATION
Overall Outside Diameter18.125"
Baffle Cutout Diameter16.625"
Depth8.875"
# Mounting Holes8

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is 2268HPL. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: 2268HPL. Speaker Material: Speaker Driver. Power Handling (RMS): 800 Watts. Power Handling (Max): 1, 600 Watts. Impedance: 8 Ohms. Sensitivity: 96 dB 1W/1m. Cone Material: Paper. Magnet Material: Neodymium. Suitable for the following model professional speaker: 1. SRX718S subwoofer.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Factory 2268HPL Neodymium Speaker Driver, 18 Inch Subwoofer Speaker?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Factory 2268HPL Neodymium Speaker Driver, 18 Inch Subwoofer Speaker cost?

The published price is US$99.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
