Fd18K4 4 Channels DSP Digital PRO Audio Power Amplifier with Fir
Speaker Amplifiers & Audio Processors

Fd18K4 4 Channels DSP Digital PRO Audio Power Amplifier with Fir

Model: FD18K4 Customization available Cables, Adapters & Audio Electronics
US$990.001–14 Pieces
US$960.0015+ Pieces
MOQ 1 Pieces
Type
Professional Amplifier
Usage
KTV, Bar, Disco
Used For
Professional
Tube Type
Transistor Amplifier
Function
Amplifier Combined
Sound Channel
4
Send Inquiry Full specifications

Specifications

Product nameFd18K4 4 Channels DSP Digital PRO Audio Power Amplifier with Fir
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
TypeProfessional Amplifier
UsageKTV, Bar, Disco
Model NO.FD18K4
Used ForProfessional
Tube TypeTransistor Amplifier
FunctionAmplifier Combined
Sound Channel4
Output Number4
Voltage90V-240V
Element NumberPush-Pull Amplifier
Conductive ModeD
8ω Stereo Power(RMS)4X1800W
4ω Stereo Power(RMS)4X2800W
2ω Stereo Power(RMS)4X4500W
Damping Factor≥5000
DSP ControlUSB
Fir Filter4*2048 Taps
Net Weight10.3kg
Gross Weight13kg
Warranty2 Years
Transport PackageExport Standard Durable Carton Box
Specification480x430x44mm
OriginChina
HS Code8518400000
Production Capacity2000 Pieces/Month
Package Size57.00cm * 56.00cm * 11.00cm
Package Gross Weight14.000kg
Lead Time5 days (1 - 10 Pieces) 15 days (11 - 50 Pieces) To be negotiated ( > 50 Pieces)
The delivery timeit is 8-10 days if by air; it is 45-60 days if by sea.
PriceUS$990.00 1-14 Pieces US$960.00 15+ Pieces
SupplierAscsonic Audio Technology Co., Ltd
Data retrieved2026-10-23

Available options

Voltage90V-240V
8ω Stereo Power(RMS)4X1800W
4ω Stereo Power(RMS)4X2800W
2ω Stereo Power(RMS)4X4500W

Additional data

FD18K4 4CH 1U Class D 18000 Watts Dj FIR DSP Digital Amplifier for Live House
ITEMFN18K4(with DANTE&FIR)FD18K4(with FIR)D18K4
8Ω Stereo Power(RMS)1800W ×4
4Ω Stereo Power(RMS)2800W ×4
2Ω Stereo Power(RMS)4500W ×4
8Ω Bridged Power(RMS)5600W x2
4Ω Bridged Power(RMS)9000W x2
Frequency response±0.5dB
1KHz THD<0.03%
Signal-to-Noise Ratio 8Ω, 1kHz,1v Sensitivity>=104dB
Input sensitivity (rated power 8Ω)0.775V/1V/32dB selectable
Cross-talk( 20Hz- 1kHz, below Rated Power )>=70 dB
Input Connectors(per channel)3-pin XLR, balanced
Output Connectors (per channel)Neutrik speakON
ClassD
ProtectionUnder voltage, DC, Over temperature, Over load limiter,short protection
DSP FuctionMUTE, Polarity, Gain, Delay, Limiter, Mixer, FIR, PEQ, ALLPASS, XoverN/A
DSP ControlUSB and DANTEUSB
FIR Filter4*2048 Taps
DANTENetwork Audio Controland TransportN/A
Display2.0 "
Operating Voltage90V-260V
Input Impedance20kΩ(Balance), 0kΩ(Unbalance)
Damp Factor>=5000
Dimensions(WXHXD) mm480x430x44mm
Packing dimension (mm)532x522x103mm
Net weight(kg)10.3kg
Gross weight(kg)13kg

Product description

The supplier lists this product as Professional Amplifier. Its stated application is KTV, Bar, Disco. The listed model is FD18K4. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: FD18K4. 8ω Stereo Power(RMS): 4X1800W. 4ω Stereo Power(RMS): 4X2800W. 2ω Stereo Power(RMS): 4X4500W.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Fd18K4 4 Channels DSP Digital PRO Audio Power Amplifier with Fir?

The listed minimum order quantity is 1 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Fd18K4 4 Channels DSP Digital PRO Audio Power Amplifier with Fir cost?

The published price is US$960.00 – 990.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
